Measurement range: Humidity measurement range is 0~100%RH, temperature measurement range is -40~80℃.
Accuracy: Temperature accuracy is ±1℃, humidity accuracy is ±3%RH, to ensure the accuracy of measurement.
Output signal: The output signal of the sensor terminal board is 4~20mA DC, this signal type is easy to connect and integrate with various control systems and data acquisition devices.
Working voltage and current: Under the condition of 12V DC power supply, the working current is less than 35mA, and the voltage is 24V.
Operating temperature range: The module’s operating temperature range is 0°C to 55°C, which can operate stably in a variety of environmental conditions.
Control type: Usually used to monitor and regulate parameters such as temperature, pressure, flow rate in industrial processes, and maintain their stability within a set range.
Input and output:
Input: Can receive signals from various sensors, such as temperature sensors, pressure sensors, etc.
Output: Control signals can be sent to actuators, such as valves, regulating valves, etc.
Program mode: Up to 30 program modes, each program mode can have up to 99 program segments.
Interface: Support RS-485, Ethernet communication (with serial port gateway function), CC-Link, PROFIBUS-DP and other communication protocols.
Display language: Support English, German, French, Spanish and other languages.
Data transfer rate: The FBM232 supports Ethernet transfer rates of 10 Mbps/100 Mbps.
Communication capability: Can communicate with up to 64 field devices.
Data integration capability: Each card can provide data integration capability of up to 2000 DCI (Distributed Control Interface) modules.
Protocol support: FBM232 has standard data communication drivers (Modbus, ModbusTCP/IP, OPC, etc.), and can also be developed and loaded according to customer needs for specific communication protocols.
Environment adaptability: The FBM232 and its wiring terminals are suitable for installation in Class1Division2 and Zone2 environments and comply with G3 (harsh) environment standards.
Power and Signal: The FOXBORO FBM232 P0926GW controller (PWM and fault) signal is compatible with 5 V CMOS logic and can also be adjusted to 15 V level using an external resistor divider.
Function: SDSS-FEX-4A is mainly used for the output control of frequency converter, which can process analog signals, such as 0 ~ 10V/5V voltage signals or 0/4 ~ 20mA current signals.
Connection mode:
Impedance matching: Select the PLC output module according to the input impedance of the inverter to achieve impedance matching between the two.
Voltage range: When the voltage signal range of the inverter and PLC is different, appropriate measures need to be taken, such as series resistance for voltage division, to ensure that the two work within the normal voltage range.
Shielding measures: In order to prevent the weak current control signal from interference by external strong signals, it is recommended to use shielded cables or stranded cables.
Versatility: The CMA198 module supports many types of input and output signals, such as analog signals, digital signals, switching signals, etc., and can adapt to different application requirements.
Signal processing: The module can process and convert input signals, such as converting analog signals to digital signals, or filtering, amplifying and other operations to ensure data accuracy and stability.
Data acquisition: The CMA198 module can collect data of sensor signals in real time and transmit it to the control system or monitoring system in order to monitor the status of industrial processes in real time.
Control function: In addition to data acquisition, the module can also be used to control the actuator and perform corresponding actions according to preset logic conditions and control algorithms, such as adjusting valves, adjusting motor speed, etc.
Communication interface: The CMA198 module is equipped with various communication interfaces, such as Modbus, Ethernet, etc., to achieve data exchange and communication with other devices or systems.
