Parameters and specifications
Number of channels: The module has 8 universal input channels and 2 CJC (common) channels, all input channels are divided into two equal groups.
Signal type: Support voltage, current, resistance and other input signals, including thermocouples and resistance temperature detectors (RTDS).
Data type: The data type of each channel is 16-bit integer and 32-bit floating point.
Scale transform function: The analog scale transform function is integrated, which can convert the analog signal collected into the corresponding different numerical output.
series
Series: IC695ALG600 is the analog input module of GE Fanuc RX3i series.
Resolution: The VMIVME-3122-020 has a 16-bit digital resolution.
Gain: Has program-controlled gain.
Conversion rate: Optional conversion rate.
Input channel: provides 64 differential or single channel automatic scanning functions.
Operation mode: Supports multiple operation modes, including automatic scanning, data burst, and external synchronization.
Input range: A/D converter range is ± 2.5V, ±5v, ±10v, 0 to + 5v, 0 to + 10v.
series
The VMIVME-3122-020 is a high-performance 16-bit analog-to-digital converter board from General Electric (GE) that is part of VMIC’s VMEbus analog input/output product family.
Parameters and specifications
Model: IC695CPU310-GV
Series: GE Fanuc RX3i series
CPU frequency: 300 MHz
Memory: 10 MB RAM and 10 MB flash
Supported Serial protocols: Modbus RTU Slave, SNP, and Serial I/O
LED indicators: Eight LED indicators on the front of the chassis are used to display the system status
Programming method: Support ladder diagram, structured text, C or function block diagram programming language
Block support: Up to 512 blocks are supported, with a maximum size of 128 KB for each block
Floating-point data format support: Floating-point data format is supported
Parameters and specifications
Model: IC693CPU363
Series: 90-30 series PLC system
User logical memory: 240KB
Input/output capacity: 4KB
Number of supported racks: 8
Boolean execution speed: 0.22 ms per thousand logic (Boolean contact)
Processor type: 80386X, 25MHz speed
Power required for operation: +5VDC, current 890mA
Working environment temperature: 0 to 60 degrees
Communication capability: The IC695PBM300 is a Profibus DP master module designed to communicate with up to 125 DP slave stations.
Data transfer: Supports data transfer sizes of 244 bytes input and 244 bytes output per device, and supports up to 3.584 bytes input data and 3.584 bytes output data.
Data rate: All standard data rates are supported, including 9.6 kBit/s, 19.2 kBit/s, 93.75 kBit/s, 187.5 kBit/s, 500 kBit/s, 1.5 MBit/s, 3 MBit/s, 6 MBit/s, and 12 MBit/s.
Series:
The IC695PBM300 is part of Emerson Automation’s PACSystems RX3i Programmable Automation controller (PAC) family.
Parameters and specifications
Working voltage: 24VDC
Operating temperature: -40℃ to 70℃
Operating humidity: 5% to 95%
Communication speed: 100Mbps
Communication protocol: Ethernet /IP
Supported chip: FPGA
Product specifications: Size 125mm x 72mm x 138mm, weight 0.5kg
Case material: metal
Mounting method: DIN rail mounting
Applicable model: RX3i controller
Size and weight
Dimensions: 125mm x 72mm x 138mm
Parameters and specifications
Brand: GE Fanuc (or GE General Electric)
Model: IC695CMM004
Communication protocol: Supports Modbus, DNP3 and other protocols
Serial ports: Provides 8 separate and isolated serial ports (note: different from the 4 ports mentioned in the first search result, but may be a later version or newer description)
Baud rate: from 1200 to 115.2 thousand baud
Power requirements: 0.7 amps at 3.3 volts DC, 0.15 amps at 5 volts DC
Maximum overvoltage rating: +/-25 volts
Minimum inter-channel crosstalk: -55 dB
Isolation of ports from the backplane: 250 V AC continuous
Port to port isolation: 500 V DC continuously and 710 V DC for up to 1 minute
Operating temperature range: 0 to 60 degrees Celsius
Parameters and specifications
Model: IC697CMM742.
Main application: This module is mainly used in the 90-70 series PLC (Programmable logic controller) system.
Network Protocol support: Supports a variety of network protocols, such as IEEE 802.2 Logical Link Control Class I LAN and IEEE 802.3 Media Access Control 10Mbps LAN.
Network port: It has three network ports, including 10Base-T RJ-45 port, 10Base2 BNC port and AUI port.
Communication rate: The maximum communication rate of 1Mbps is supported.
Supported communication protocols: Modbus RTU, Modbus ASCII, Profibus DP, etc.
Voltage and current: Absorb 2 amps of large backplane current at +5 volts DC and 0.5 amps of large backplane current at +12 volts DC.
Operating voltage range: 85~264VAC.
Output voltage: 24VDC.
Output power: 360W.
Input current: 500mA.
