RP7517A 1009-1

Description

‌Parameters and Specifications‌:

–‌Model Number‌: RP7517A 1009-1
–‌Manufacturer‌: Honeywell
–‌Input Voltage‌: 220/240V (-15% to +10%), 50Hz (40-60Hz)12
–‌Primary Current‌: 0.25A2
–‌Ignition Time‌: Continuous ignition not exceeding 1 minute12
–‌Ignition Voltage‌: 2x7Kv2
–‌Secondary Current‌: 40mA rms2
–‌Secondary Frequency‌: 20kHz2
‌Dimensions and Weight‌:

–‌Size (Inches)‌: 2 7/16″ wide x 3 5/8″ high x 2″ deep34
–‌Size (Millimeters)‌: 62mm wide x 92mm high x 52mm deep35
–‌Weight‌: Approximately 280 grams

‌Series‌:

• Part of Honeywell’s signal converter series, designed for a variety of industrial applications2
  ‌Features‌:

–‌Wide Voltage Range‌: Accepts a wide range of input voltages, enhancing compatibility with different power sources12
–‌High Ignition Voltage‌: Capable of producing high ignition voltages, suitable for igniting various fuels2
–‌Continuous Ignition Control‌: Allows for controlled ignition durations, preventing damage due to prolonged ignition12
–‌Compact Design‌: Offers a compact design for easy installation in industrial control cabinets35
‌Functions and Applications‌:

–‌Signal Conversion‌: Converts electrical signals into ignition signals, enabling precise control of ignition processes2
–‌Flame Ignition‌: Commonly used in flame ignition systems, ensuring reliable and safe ignition of industrial burners6
–‌Industrial Automation‌: Integral to industrial automation systems, contributing to improved process control and efficiency2
–‌Safety‌: Enhances safety by providing reliable ignition control, reducing the risk of accidents or equipment damage
