Description
Parameters
| Parameter | Specification |
|---|---|
| Ethernet Ports | 2x 10/100/1000BASE-T (RJ45) with PRP/HSR redundancy |
| Protocols Supported | Modbus TCP (client/server), OPC UA (server), PROFINET, SNMP (agent), HTTPS |
| Data Points | Up to 2000 (configurable read/write) |
| Concurrent Clients | Up to 20 |
| Update Rate | Configurable: 10ms–60s per data group |
| Redundancy | PRP (Parallel Redundancy Protocol) or HSR (High-availability Seamless Redundancy) |
| Security | TLS 1.2, role-based access control (RBAC), secure boot |
| Web Server | Built-in HTTPS (configuration, diagnostics) |
| Diagnostics | Link status, protocol errors, data integrity checks, connection status, CPU/memory usage |
| Memory | 512MB SDRAM, 128MB Flash |
| Power Supply | 24VDC, 500mA |
| Operating Temp | -40°C to +70°C |
| Mounting | Eurocard (6U, 160mm) |
| Certifications | UL, CSA, ATEX Zone 2, CE, DNV GL |
Advantages & Features
-
Multi-Protocol Gateway – The ABB 3BHE021951R0124 supports Modbus TCP, OPC UA, and PROFINET simultaneously, eliminating the need for multiple standalone gateways.
-
Redundant Communication – Dual Ethernet ports with PRP/HSR ensure zero-loss failover for mission-critical applications.
-
Enhanced Cybersecurity – TLS 1.2 encryption, role-based access control, and secure boot make the ABB 3BHE021951R0124 compliant with NERC CIP requirements.
-
Built-in Web Server – Secure HTTPS interface for remote configuration and diagnostics without additional software.
-
ABB System Integration – Native support for System 800xA and Procontrol P14, ensuring seamless data exchange.
-
High Data Capacity – Supports up to 2000 data points for large-scale plant integration.
Application Cases
-
SCADA Integration – The ABB 3BHE021951R0124 transmits turbine and generator data to a utility SCADA system via Modbus TCP and OPC UA.
-
DCS Communication – Connects ABB System 800xA to a third-party DCS (e.g., Honeywell, Emerson) via PROFINET.
-
Remote Monitoring – Provides secure OPC UA data to remote condition monitoring systems.
-
Plant-Wide Network Integration – Bridges ABB control systems with plant-wide Ethernet networks using PRP redundancy.
Competitor Comparison
| Feature | ABB 3BHE021951R0124 | Siemens 6ES7158-3AA01 | GE DS3860NPSM | Rockwell 1756-EN2T |
|---|---|---|---|---|
| Data Points | 2000 | 1000 | 5000 | 500 |
| Concurrent Clients | 20 | 20 | 50 | 10 |
| Protocols | Modbus, OPC UA, PROFINET | Modbus, PROFINET | Modbus, OPC UA, DNP3, IEC 61850 | EtherNet/IP, Modbus |
| Redundancy | PRP/HSR (zero-loss) | PRP | PRP/HSR | RSTP |
| Security | TLS 1.2, RBAC, secure boot | TLS 1.0 | TLS 1.3, RBAC, LDAP | TLS 1.2 |
| Web Server | Yes | No | Yes | Yes (limited) |
| Integration | ABB System 800xA | Siemens TIA | GE Mark VIe | Rockwell Logix |
The ABB 3BHE021951R0124 offers robust protocol support and PRP/HSR redundancy, making it a strong choice for ABB-based power generation systems.
Selection Suggestions
-
Choose for ABB System 800xA applications requiring secure, redundant communication to third-party DCS, SCADA, or condition monitoring systems.
-
For OPC UA-only applications, the lower-cost 3BHE021951R0123 (OPC UA only) may be sufficient.
-
For SIL 2 applications, use with appropriate external voting logic (module is SIL 1 rated).
-
Enable PRP/HSR redundancy for mission-critical networks requiring zero-loss failover.
-
Pair with standard Ethernet cables and ABB termination units.
Precautions
-
Network Segmentation – Place the ABB 3BHE021951R0124 on a dedicated control network segment, separate from office IT networks.
-
Firewall Configuration – Ensure required ports are open: Modbus TCP (502), OPC UA (4840), PROFINET (34962–34964), HTTPS (443).
-
Data Point Configuration – Monitor CPU load; reduce update rates for non-critical data to maintain margin.
-
Cybersecurity Hardening – Change default passwords immediately. Disable unused protocols and services.
-
Power Supply – The module draws 500mA from 24VDC. Ensure adequate capacity.
-
Firmware – Requires ABB System 800xA firmware version 6.0 or higher.
-
ESD Handling – Use ESD-safe practices when handling the module.
