81EU01E-E

Description

–‌Parameters‌:
–‌Communication Protocols‌: PROFIBUS DP, CANopen, Modbus RTU, Ethernet (in some models)12
–‌Transmission Rates‌:
– PROFIBUS DP: 960 kbps to 6 Mbps1
– CANopen: 125 kbps to 1 Mbps1
– Modbus RTU: 9600 bps to 115200 bps1
– Ethernet (if applicable): High-speed Ethernet connectivity2

–‌Specifications‌:
–‌Power Supply‌: 24 VDC1
–‌Power Consumption‌: 2 W1
–‌Operating Temperature‌:
– -20°C to 60°C (as per some sources)1
– -40°C to 70°C (for certain applications)2
–‌Protection Rating‌: IP67, ensuring dust-tight and water-resistant capabilities

–‌Dimensions & Weight‌:
–‌Dimensions‌:
– 110 mm x 22.5 mm x 70 mm (as per some sources)1
– 90 mm x 30 mm x 22 mm (another reported dimension)3
–‌Weight‌: Approximately 0.2 kg13

–‌Series‌:

• Belongs to ABB’s AC500 I/O series1
• Also part of ABB’s ET200S I/O system series3
• Could be included in ABB’s VersaMax industrial control product series for certain models2

–‌Characteristics‌:
–‌High-Speed Communication‌: Supports high data transmission rates for real-time control applications1
–‌Multiple Protocol Support‌: Enables seamless integration with various devices and systems12
–‌High Reliability‌: Designed for industrial environments, withstanding temperature extremes and shock2
–‌Ease of Configuration‌: User-friendly interface and software support for simplified setup and programming2

–‌Role‌:
–‌Communication Bridge‌: Acts as a communication interface between different devices and systems in industrial automation setups2
–‌Data Transmission‌: Enables the transfer of data between controllers, sensors, actuators, and other devices4
–‌System Integration‌: Facilitates the integration of various components within an industrial control system, enhancing overall efficiency and reliability
