Description
Parameters and Specifications:
–Brand: General Electric (GE)12
–Series: Mark VI
–Component Type: Relay Fuse and Power Sensing Card
–Fuse Ratings:
–Rated Current: 3.15A15
–Rated Voltage: 500VAC/400VDC1
–Number of Fuses: 121
Dimensions and Weight:
–Size: 23cm in length (specific width and height may vary)2
–Weight: 0.2kg2
Series:
- Part of GE’s Mark VI series of control systems
Features:
–Scalability: Offers scalable redundancy levels up to 11
–Compatibility: Can be used with other boards in the Mark VI series, such as TDBS, SRLY, and TDBT boards56
–Mode Flexibility: Can operate in simplex, redundant, or TMR (Triple Modular Redundancy) modes56
–Power Distribution: Provides induction and fused power distribution for the first six initial relay outputs and dedicated power for the final relay outputs56
–Fault Detection: Detects different states of the six pairs of fuses when used with isolation voltage on TDBS56
Functions:
–Power Sensing and Relay Control: Senses power levels and controls relays, crucial for safe and efficient operation of industrial control systems1
–Discrete Input/Output Module Support: Supports PDIO (Parallel Discrete Input/Output) modules in the Mark VI system56
–TMR Capability: Enables high availability and reliability through TMR configurations
