HONEYWELL CC-PWR401

Description

1. Product Overview

2. Product Parameters

2.1 Core Power Specifications

• Input Voltage: 100-240V AC (single-phase), 50/60Hz; 120-300V DC (optional)
• Output Voltage: 24V DC ±1% (dual redundant channels)
• Output Current: 10A per channel (20A total for redundant configuration)
• Efficiency: ≥92% (full load), ≥88% (50% load)
• Ripple & Noise: ≤50mV p-p (24V DC output)
• Redundancy: 1+1 hot standby with automatic switchover (<5ms transition time)

2.2 Electrical & Protection Parameters

• Protection Features: Overvoltage protection (28V DC max), overcurrent protection (12A per channel), short-circuit protection, thermal shutdown, reverse polarity protection
• Diagnostic Features: Input voltage monitoring, output voltage/current monitoring, fault status feedback (dry contact + digital signal), LED status indicators (power, fault, redundancy)
• Communication Interface: Modbus TCP/IP for integration with Experion PKS (remote diagnostics, alarm reporting)
• Power Consumption: ≤5W (no-load), ≤250W (full load)

2.3 Environmental & Mechanical Parameters

• Operating Temperature: -20°C to +60°C (industrial-grade range)
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5% to 95% (non-condensing), IP20 protection (rack-mounted)
• Vibration Resistance: 5-2000Hz, 2g (IEC 60068-2-6, X/Y/Z axes)
• Shock Resistance: 15g (11ms half-sine wave, IEC 60068-2-27)
• Mounting: Honeywell Experion PKS/Safety Manager rack-mounted, hot-swappable (plug-in module)
• Dimensions: 175mm (W) × 125mm (H) × 35mm (D), standard rack compatibility
• Cooling: Forced air (internal fan) + passive convection

2.4 Certifications & Compliance

• Safety Certifications: SIL 3 (IEC 61508/61511), TÜV Rheinland, ATEX Zone 2 (Ex nA IIC T4)
• Industry Certifications: CE, UL/cUL Class 1 Div 2, FCC Class A, RoHS, IEC 61010-1 (industrial control equipment)
• Compatibility: Honeywell Experion PKS C200/C300 controllers, Safety Manager SIS, all Honeywell I/O modules (CC-PDOB01, CC-PAINA1)
• MTBF: ≥1,500,000 hours (per Telcordia SR-332 standards)

3. Advantages & Features

1. SIL 3 Redundant Power Delivery: HONEYWELL CC-PWR401 provides 1+1 hot standby power with <5ms switchover, eliminating single points of failure and ensuring compliance with the highest safety standards for critical SIS/DCS applications.
2. High Efficiency & Reliability: With ≥92% full-load efficiency and comprehensive protection features (overvoltage/overcurrent/short-circuit), HONEYWELL CC-PWR401 minimizes energy waste and protects downstream components from power-related damage.
3. Advanced Diagnostics & Remote Monitoring: Real-time input/output voltage/current monitoring and Modbus TCP connectivity enable remote diagnostics and alarm notification, allowing operators to address issues before they cause system outages.
4. Hot-Swappable Design: HONEYWELL CC-PWR401 supports hot-swapping in live systems, allowing module replacement without powering down safety-critical components—critical for facilities where downtime is prohibitively expensive.
5. Broad Input Voltage Range: 100-240V AC/120-300V DC input compatibility ensures operation in diverse industrial power environments, reducing the need for external voltage converters.

4. Application Fields & Cases

4.1 Application Fields

• Oil & Gas: Refinery ESD system power distribution, offshore platform SIS power supply, pipeline monitoring system power
• Petrochemical: Chemical reactor safety system power, batch process control SIS power, storage terminal emergency shutdown power
• LNG: Liquefaction plant fire/gas detection system power, regasification facility safety interlock power, storage tank control system power
• Power Generation: Turbine protection SIS power, nuclear auxiliary safety system power, renewable energy grid control system power

4.2 Typical Cases

1. Refinery ESD System Power: A major Middle Eastern refinery deployed HONEYWELL CC-PWR401 modules to power 8 redundant Experion PKS controller racks across 4 process units. The module’s 1+1 redundancy prevented a safety system outage during a primary power channel failure, avoiding a $1.2M production loss and ensuring compliance with local safety regulations.
2. LNG Plant Safety System Power: An Australian LNG liquefaction plant integrated HONEYWELL CC-PWR401 into its Safety Manager SIS to power fire/gas detection and emergency shutdown components. The module’s hot-swappable design allowed maintenance crews to replace a faulty power channel during peak production without disrupting safety operations, saving $500,000 in potential downtime costs.
3. Chemical Reactor Safety Power: A European chemical plant used HONEYWELL CC-PWR401 to supply redundant power to 12 reactor safety interlock systems. The module’s diagnostic features identified a deteriorating capacitor before it caused a power failure, enabling proactive replacement during a scheduled outage and preventing unplanned downtime.

5. Competitive Comparison

6. Selection Suggestions & Precautions

6.1 Selection Suggestions

1. Safety Level & Redundancy Needs: Choose HONEYWELL CC-PWR401 for SIL 3 SIS/DCS applications requiring redundant power (e.g., refineries, LNG plants); SIL 2 redundant PSUs are suitable for low-risk industrial environments (e.g., water treatment).
2. Load Capacity Requirements: Opt for HONEYWELL CC-PWR401 if system load exceeds 10A (e.g., large I/O rack configurations); smaller redundant PSUs suffice for low-load systems (≤8A).
3. System Compatibility: Select HONEYWELL CC-PWR401 for integration with Honeywell Experion PKS/Safety Manager systems to ensure seamless communication and diagnostic support; third-party PSUs may lack compatibility with Honeywell’s safety protocols.

6.2 Precautions

1. Installation Guidelines:
   • Install HONEYWELL CC-PWR401 in Honeywell-certified racks only; ensure proper grounding (≤4Ω) and separate input power feeds for redundant channels (to maximize fault tolerance).
   • Use 16AWG or larger wiring for output connections (24V DC) to minimize voltage drop, and comply with local electrical codes for hazardous area installations (e.g., Zone 2/Class 1 Div 2).
2. Configuration Notes:
   • Configure fault response settings (e.g., alarm notification, automatic switchover) via Experion Configuration Studio to align with site safety procedures.
   • Enable remote diagnostics and status reporting to monitor power module health from the central control room.
3. Troubleshooting:
   • For output voltage faults: Check input power supply, verify load current (ensure it does not exceed 10A/channel), and inspect for short circuits in downstream wiring.
   • For redundancy alarms: Test the standby channel (via Experion Configuration Studio) and replace the faulty channel if switchover fails.
4. Maintenance:
   • Inspect cooling fans every 12 months (clean or replace if damaged) to prevent thermal shutdown, and test battery backup (if installed) quarterly to ensure uninterrupted power during input outages.
   • Calibrate voltage/current monitoring sensors every 2 years using a calibrated multimeter to maintain accuracy.
   • Stock spare HONEYWELL CC-PWR401 modules for critical applications—lead times for Honeywell SIS power components may exceed 10 weeks.
