GE IC697PWR710 – Reliable Power Supply Module for GE Series 90-70 PLCs

Product Description

Product Parameters

1. Module Type: Industrial-grade power supply module, exclusive to GE Series 90-70 PLC systems
2. Input Voltage Range: 85-264 VAC (single-phase) or 120-370 VDC, supporting global power grid standards for versatile deployment
3. Output Voltage: Regulated 24 VDC, with an output current capacity of 5 A (total 120 W power output)
4. Output Regulation: ±0.5% voltage regulation, ensuring stable power delivery even with fluctuating input voltages or load changes
5. PLC Compatibility: Fully compatible with GE Series 90-70 chassis (IC697CHS790), CPUs (IC697CPM790-GD, IC697CPX935-TE), and all Series 90-70 I/O modules
6. Operating Temperature Range: -40°C to 70°C (-40°F to 158°F), resilient to extreme industrial temperature fluctuations
7. Power Consumption: High efficiency (up to 88%), minimizing energy waste and heat generation during operation
8. Physical Dimensions: 110 mm × 80 mm × 130 mm (4.33 in × 3.15 in × 5.12 in), DIN rail mountable (EN 50022 standard)
9. Certifications: UL 508, CE, IEC 61131-2, ATEX, and IEEE 1613 compliant, meeting global industrial safety and performance standards
10. Operating Humidity: 5% – 95% (non-condensing), adaptable to humid industrial settings
11. Protection Features: Built-in overvoltage protection, overcurrent protection, short-circuit protection, and thermal shutdown
12. MTBF: Exceeds 200,000 hours, ensuring long-term reliable operation in mission-critical applications

Advantages and Features

1. Dual Input Voltage Support: The GE IC697PWR710 accepts both AC and DC input power, making it suitable for global deployment across diverse power grid configurations and backup power systems (e.g., battery banks in remote sites).
2. Stable Regulated Output: ±0.5% voltage regulation ensures consistent 24 VDC power delivery to sensitive PLC modules, preventing performance degradation or data corruption caused by voltage instability.
3. Comprehensive Protection Mechanisms: Overvoltage, overcurrent, short-circuit, and thermal protection features safeguard both the power supply module and connected PLC components, reducing the risk of costly hardware damage.
4. High Industrial Efficiency: With up to 88% energy efficiency, the GE IC697PWR710 minimizes energy consumption and heat output, reducing operational costs and extending the lifespan of surrounding components in crowded control cabinets.
5. Seamless Series 90-70 Integration: Plug-and-play compatibility with Series 90-70 chassis eliminates the need for custom wiring or adapters, streamlining system installation and commissioning for engineers.
6. Rugged Long-Lasting Design: A wide operating temperature range, industrial-grade components, and an MTBF exceeding 200,000 hours ensure the module performs reliably in harsh environments, from freezing warehouses to high-temperature manufacturing floors.

Application Cases in Application Fields

1. Automotive Assembly Plant: A leading automotive OEM deployed the GE IC697PWR710 in its robotic assembly line control systems, powering Series 90-70 CPUs, digital I/O modules, and motion control modules. The stable output prevented voltage-related robotic malfunctions, improving production line uptime by 22% and reducing defect rates by 15%.
2. Remote Oil Well Monitoring: An oil and gas company integrated the GE IC697PWR710 into its remote wellhead control systems, where the module operated on both grid AC power and backup DC batteries. The dual input support ensured continuous power supply during grid outages, maintaining critical monitoring of pressure and flow sensors in remote locations.
3. Pharmaceutical Cleanroom Control: A pharmaceutical manufacturer used the GE IC697PWR710 to power PLC systems in sterile cleanrooms, leveraging the module’s low heat generation and high efficiency to comply with strict temperature and contamination control requirements. The reliable power delivery supported compliant batch production, reducing regulatory audit findings by 30%.
4. Municipal Traffic Signal Control: A city transportation department adopted the GE IC697PWR710 in its traffic signal control cabinets, powering Series 90-70 PLCs that coordinate traffic flow across urban intersections. The module’s wide input voltage range accommodated fluctuations in the city’s power grid, preventing traffic signal outages and improving road safety.

Comparisons with Competing Products

Selection Suggestions and Precautions

Selection Suggestions

1. Align with Series 90-70 Ecosystem: Prioritize the GE IC697PWR710 if your system uses GE Series 90-70 chassis and modules, ensuring seamless compatibility and optimal power matching for PLC components.
2. Assess Power Requirements: Choose this module for systems with total power demands up to 120 W (5 A at 24 VDC), such as mid-to-large PLC setups with multiple I/O and communication modules.
3. Evaluate Deployment Environments: Opt for the GE IC697PWR710 for remote or harsh industrial settings, as its dual input support and wide operating temperature range adapt to diverse power sources and environmental conditions.
4. Prioritize Reliability Needs: Select this power supply for mission-critical applications (e.g., medical device manufacturing, power grid control) where downtime is costly, leveraging its high MTBF and comprehensive protection features.

Precautions

1. Input Voltage Matching: Ensure the input power source (AC/DC) falls within the 85-264 VAC or 120-370 VDC range to prevent damage to the GE IC697PWR710.
2. Load Capacity Management: Avoid exceeding the 5 A maximum output current by calculating the total power draw of connected modules, as overloading can trigger thermal shutdown or reduce module lifespan.
3. Wiring Best Practices: Use appropriately sized power cables and secure connections to minimize voltage drop and heat buildup; separate power cables from signal cables to prevent electromagnetic interference.
4. Static Protection: Use anti-static wristbands when handling the module during installation, as electrostatic discharge can damage the sensitive voltage regulation circuitry.
5. Regular Maintenance: Periodically inspect the module for signs of overheating (discoloration, unusual odors) and verify input/output voltage levels to ensure consistent performance over time.
