GE Fanuc DS3800DFXD

Advantages & Key Features

• Integrated Field Driver: The GE Fanuc DS3800DFXD includes an integrated driver for field power stage control.

• Precise Field Excitation: Provides accurate field excitation for optimal motor performance.

• Field Weakening Control: Enables extended speed range operation.

• Field Loss Protection: Detects field loss conditions for safe operation.

• Integrated Protection: Field overcurrent and overvoltage detection ensure safe operation.

• Extended Temperature Range: -10°C to +65°C for demanding environments.

• Diagnostic LEDs: 12-LED indicator matrix provides comprehensive real-time status.

• Conformal Coating: Protects against dust, moisture, and chemicals.

Application Fields

• Steel & Metal Processing: Field excitation for rolling mill DC motors.

• Paper & Pulp: Field excitation for paper machine DC drives.

• Material Handling: Field excitation for crane and conveyor DC motors.

• General Industrial: Any GE DC300/DC200 drive requiring field excitation with driver.

Comparison with Alternatives

Key Differentiator: The GE Fanuc DS3800DFXD offers an integrated field driver for complete field excitation and control.

Selection Suggestions & Precautions

1. Field Excitation Requirements: Verify your field excitation and driver requirements match the board’s specifications.

2. Field Wiring: Use appropriate wiring for field connections.

3. Calibration: Verify scaling and calibration for accurate field control.

4. Capacitor Aging: NOS boards stored >5 years may require capacitor inspection.

5. Test Report Required: Request verification of field excitation and driver functionality.

6. Spare Strategy: For critical applications, maintain a tested spare.

Final Recommendation

The GE Fanuc DS3800DFXD is a reliable digital field excitation and driver board for GE DC300/DC200 drive systems, providing precise field excitation with integrated driver capability. Prioritize suppliers with comprehensive testing capabilities. For critical applications, maintain a tested spare to minimize downtime. As GE has discontinued this series, sourcing through reputable aftermarket suppliers with refurbishment and testing capabilities is recommended.
