YASKAWA CP-317/217IF

Description

Product Description

Technical Parameters

• Device Type: Communication Interface Module for Yaskawa MP Series Machine Controllers
• Supported Protocols: Ethernet/IP, Modbus TCP/RTU, PROFINET IO, Yaskawa MECHATROLINK-III
• Communication Ports: 2× Gigabit Ethernet ports, 1× RS-485 port, 1× internal MECHATROLINK-III port
• Data Transfer Rate: Up to 1 Gbps (Ethernet), 100 Mbps (MECHATROLINK-III)
• Operating Voltage: 24 V DC ±10%
• Operating Temperature Range: -10°C to +60°C
• Protection Rating: IP20 (cabinet-mounted installation)
• Isolation: 2500 V AC between communication ports and controller logic
• Compatibility: Yaskawa MP3000/MP2000 Machine Controllers, MotionWorks IEC Software, Yaskawa HMIs
• Certifications: CE, UL, CSA, IEC 61131-2, RoHS Compliant

Advantages and Features

1. Multi-Protocol Flexibility

   YASKAWA CP-317/217IF supports a comprehensive range of mainstream industrial communication protocols, eliminating the need for protocol converters and enabling smooth integration with both Yaskawa and third-party automation equipment. This flexibility reduces system complexity and deployment costs.

2. High-Speed Real-Time Data Transmission

   With Gigabit Ethernet and MECHATROLINK-III support, YASKAWA CP-317/217IF delivers ultra-low latency data transfer, critical for synchronized motion control applications such as multi-axis robotic systems and high-speed packaging lines.

3. Rugged Industrial Design

   Equipped with EMI shielding and reinforced circuit boards, YASKAWA CP-317/217IF resists electrical interference from nearby motors and power equipment, maintaining stable communication even in high-noise factory settings. Its wide operating temperature range also suits diverse industrial environments.

4. Seamless Yaskawa Ecosystem Integration

   Optimized for Yaskawa’s MP Series controllers, YASKAWA CP-317/217IF integrates seamlessly with MotionWorks software for one-click configuration, real-time diagnostics, and motion control parameter tuning. It also supports remote monitoring for predictive maintenance.

5. High Reliability and Durability

   Built with industrial-grade components and a fanless design, YASKAWA CP-317/217IF has a mean time between failures (MTBF) of over 150,000 hours, ensuring long-term, maintenance-free operation in continuous production environments.

Application Cases

• Robotic Assembly Lines: YASKAWA CP-317/217IF enables real-time communication between Yaskawa MP controllers and articulated robots, synchronizing multi-axis movements to achieve precise component assembly in automotive electronics manufacturing.
• High-Speed Packaging Machinery: Integrated into Yaskawa-controlled packaging lines, the module connects motion controllers to sensors and conveyor drives, ensuring accurate product positioning and reducing packaging errors by 30%.
• Semiconductor Manufacturing Equipment: Used in wafer handling systems, YASKAWA CP-317/217IF supports high-speed data exchange for ultra-precise motion control, meeting the strict accuracy requirements of semiconductor processing.

Comparison with Competitors

• Protocol Completeness: Unlike competing communication modules that support only 2–3 protocols, YASKAWA CP-317/217IF offers full support for 4 mainstream industrial protocols, providing greater flexibility for heterogeneous system integration.
• Real-Time Performance: With MECHATROLINK-III support, YASKAWA CP-317/217IF delivers lower latency than generic Ethernet modules, making it ideal for high-precision motion control applications where timing accuracy is critical.
• Yaskawa Ecosystem Synergy: Generic communication modules require complex programming to work with Yaskawa MP controllers, whereas YASKAWA CP-317/217IF offers plug-and-play compatibility and full access to motion control functions.

Selection Recommendations and Precautions

Selection Recommendations

• Choose YASKAWA CP-317/217IF for upgrading or expanding Yaskawa MP Series machine controller systems, especially in multi-axis motion control, robotic assembly, and high-speed manufacturing applications.
• This module is ideal for projects requiring heterogeneous system integration (e.g., connecting Yaskawa controllers to PROFINET or Ethernet/IP devices) and real-time data transmission.

Precautions

• YASKAWA CP-317/217IF is designed exclusively for Yaskawa MP Series machine controllers; do not use it with non-Yaskawa controllers without official compatibility verification.
• Ensure proper grounding during installation to avoid EMI-related communication issues that may affect the performance of YASKAWA CP-317/217IF.
• Use only licensed Yaskawa MotionWorks software for configuration and firmware updates; unauthorized software may cause firmware corruption and system malfunctions.
