LXN1604-6 3BHL000986P7000

Description

LXN1604-6 3BHL000986P7000

1. Technical Specifications

• Power Supply:
  • The LXN1604 – 6 3BHL000986P7000 operates on a 24V DC power supply. The power consumption is relatively low, around 5 – 8W, which makes it energy – efficient for continuous operation.
• Input/Output Configuration:
  • Digital Inputs: It features 16 digital inputs. These inputs can accept signals from various digital sensors such as proximity sensors, limit switches, and opto – isolators. They are designed to handle input voltages in the range of 5 – 24V DC.
  • Digital Outputs: There are 4 digital outputs. Each output can drive a load with a maximum current of 1A, suitable for controlling small relays, solenoids, and indicator lights.
  • Analog Inputs: There are no analog inputs in this model.
  • Analog Outputs: There are also no analog outputs.
• Processing Speed:
  • The response time for digital input changes is less than 10ms, enabling quick reaction to changes in the monitored system.
• Communication Interfaces:
  • It supports an Ethernet interface with TCP/IP protocol, allowing for high – speed data transfer and integration into industrial Ethernet networks. It also has an RS – 485 serial port with Modbus RTU support for local communication with other devices.

2. Applications

• Industrial Automation:
  • In industrial manufacturing, it can be used to monitor and control simple production processes. For example, it can detect the presence of products on a conveyor belt using digital sensors connected to the inputs and control the operation of a sorting mechanism via the digital outputs.
• Material Handling:
  • In warehouses, it can be used to monitor the movement of goods on racks. It can receive signals from sensors that detect the position of the goods and control the operation of lifting equipment or conveyor systems.
• Building Automation:
  • In commercial buildings, it can be used to control basic lighting and access control systems. For instance, it can detect the presence of people in a room using motion sensors and turn the lights on or off accordingly.

3. Weight and Dimensions

• Weight:
  • The module weighs about 0.5 kg, which is relatively light and easy to install and handle.
• Dimensions:
  • The overall dimensions are: length – 130mm, width – 100mm, height – 30mm. Its compact size allows for installation in standard electrical cabinets or control panels.

LXN1604-6 3BHL000986P7000

4. Features

• Ethernet and Serial Communication:
  • The combination of Ethernet and RS – 485 communication interfaces provides flexibility in system integration, allowing it to communicate with a wide range of devices and control systems.
• High – Speed Response:
  • The fast response time to digital input changes ensures real – time monitoring and control of the connected processes.
• Simple Configuration:
  • It has a user – friendly configuration interface, which allows users to easily set up the module according to their specific requirements without extensive technical knowledge.

5. Stability and Reliability

• Robust Construction:
  • The module is housed in a durable plastic enclosure that provides protection against dust, moisture, and minor mechanical vibrations. This ensures stable operation in normal industrial environments.
• Fault – Tolerant Design:
  • It is designed with built – in protection mechanisms such as over – current protection and short – circuit protection for the digital outputs. These features safeguard the module from electrical faults and extend its service life.
• Quality Components:
  • The use of high – quality electronic components and strict quality control during manufacturing ensure long – term reliability and consistent performance.

6. Real – world Examples

• Textile Manufacturing:
  • In a textile manufacturing plant, the LXN1604 – 6 3BHL000986P7000 can be used to monitor the operation of spinning machines. It can detect if a thread breaks using digital sensors and stop the machine immediately via the digital outputs to prevent further damage.
• Small – Scale Logistics Center:
  • In a small – scale logistics center, it can control the operation of a small conveyor system. It can detect the arrival of packages using proximity sensors and control the movement of the conveyor belt to transfer the packages to the appropriate storage area.
