Honeywell FC-IO-0001

¥2,399.00

The Honeywell FC-IO-0001 is a fundamental Field Controller I/O module designed for Honeywell’s building automation and control systems, such as the Honeywell WEBs-AX or Niagara Framework-based platforms. This module, the Honeywell FC-IO-0001, serves as a versatile input/output interface that connects the digital control logic of a field controller to physical devices in a building or light industrial environment. It typically provides a mix of universal inputs (capable of reading analog voltage/current or digital status) and digital outputs for control. The primary function of the Honeywell FC-IO-0001 is to gather data from sensors (like temperature, humidity, or pressure) and execute control commands to actuators (such as damper motors, valve actuators, or relay coils), enabling localized control loops. Its design emphasizes flexibility, ease of installation, and reliable performance for HVAC and building management applications.

Category:

Description

Product Description

The Honeywell FC-IO-0001 is a fundamental Field Controller I/O module designed for Honeywell’s building automation and control systems, such as the Honeywell WEBs-AX or Niagara Framework-based platforms. This module, the Honeywell FC-IO-0001, serves as a versatile input/output interface that connects the digital control logic of a field controller to physical devices in a building or light industrial environment. It typically provides a mix of universal inputs (capable of reading analog voltage/current or digital status) and digital outputs for control. The primary function of the Honeywell FC-IO-0001 is to gather data from sensors (like temperature, humidity, or pressure) and execute control commands to actuators (such as damper motors, valve actuators, or relay coils), enabling localized control loops. Its design emphasizes flexibility, ease of installation, and reliable performance for HVAC and building management applications.

Product Parameters

The technical specifications for the Honeywell FC-IO-0001 I/O module are designed for building automation versatility:

  • Module Type: Field Controller Input/Output Module.

  • I/O Configuration: Commonly features a combination of universal inputs and digital outputs. A typical configuration is 4 Universal Inputs (UI) and 4 Digital Outputs (DO).

  • Universal Inputs (UI): Can be configured as:

    • Analog Input (AI): 0-10 VDC, 0-20 mA, or 4-20 mA for sensing.

    • Digital Input (DI): Dry contact (status) or pulsed input for counting.

    • Resistance Input: For measuring RTDs or potentiometers.

  • Digital Outputs (DO): Typically relay outputs with Form-A (SPST-NO) or Form-C (SPDT) contacts, rated for AC/DC switching at specific voltage and current levels (e.g., 30V DC/1A, 250V AC/2A).

  • Power Supply: Requires a 24 VAC or VDC external power source for operation and to power connected field devices.

  • Communication: Connects to the host field controller (e.g., Honeywell Spyder, WEB-600) via a proprietary communication bus or terminal block connection.

  • LED Indicators: Includes status LEDs for power, communication, and individual I/O point status.

  • Mounting: Designed for DIN rail mounting within an enclosure.

Advantages and Features

The Honeywell FC-IO-0001 offers significant advantages for building control systems:

  • Configuration Flexibility: The universal inputs on the Honeywell FC-IO-0001 allow a single module type to interface with a wide variety of sensors, reducing inventory complexity and enabling easy system changes.

  • Simplified System Design: Combining analog/digital inputs and relay outputs in one unit provides a compact, all-in-one I/O solution for controlling typical HVAC equipment like VAV boxes, fan coils, or heat pumps.

  • Easy Installation and Commissioning: Features like pluggable terminal blocks, clear labeling, and visual LEDs streamline the installation and troubleshooting process.

  • Native System Integration: As a Honeywell component, the FC-IO-0001 integrates seamlessly with Honeywell field controllers and is easily configured within Honeywell’s Niagara Workbench or WEBs-AX software.

  • Reliable Performance: Built to the industrial standards required for continuous operation in commercial building environments.

Application Cases in Industry

This I/O module is widely used in commercial and institutional building automation:

  • Variable Air Volume (VAV) Box Control: The universal inputs read space temperature and airflow, while the relay outputs control the damper actuator and reheat valve for a VAV terminal unit.

  • Fan Coil Unit (FCU) Control: Interfaces with a room thermostat (via UI), controls a 3-speed fan (via DO relays), and operates a water valve for heating/cooling.

  • Pump and Fan Control: Uses digital inputs for status feedback (e.g., flow switch, pressure switch) and relay outputs to start/stop motors or signal an external variable frequency drive (VFD).

  • Lighting Control: Can be used for daylight harvesting or schedule-based control, where inputs from photocells and outputs to lighting contactors are required.

  • Energy Metering: The universal inputs can be configured to accept pulse outputs from utility meters (gas, water, electricity) for sub-metering and energy management.

Comparisons with Competing Products

When compared to generic I/O modules or those from other building automation vendors, the Honeywell FC-IO-0001 presents specific benefits:

  • Universal Input Advantage: Many competing modules require separate analog input, digital input, and output modules. The Honeywell FC-IO-0001‘s universal inputs provide greater application flexibility and lower part count.

  • Seamless Honeywell Ecosystem Integration: Configuration, point naming, and alarming are fully integrated into the Honeywell software suite, providing a smoother workflow than integrating a third-party MODBUS I/O module.

  • Optimized for HVAC Applications: Its I/O mix and specifications are specifically tailored for common HVAC sequences, making it a more purpose-fit solution than a generic PLC digital/analog card.

  • Simplified Support and Documentation: Being part of a major OEM’s portfolio ensures access to standardized training, application notes, and technical support specific to building automation.

Selection Suggestions and Precautions

Proper selection and installation are key to reliable operation:

  1. Verify Controller Compatibility: Confirm that the Honeywell FC-IO-0001 is compatible with your specific Honeywell field controller model (e.g., Spyder, WEB-600) and that the controller has an available port or capacity for it.

  2. Plan Input Configuration: Before installation, determine the configuration for each universal input (Voltage, Current, Digital, etc.) as this will dictate the wiring and sensor selection.

  3. Check Relay Ratings: Carefully review the relay output specifications (voltage, current, inductive load rating). Do not exceed the ratings when connecting loads like contactor coils, actuators, or pilot lights. Use external relays for larger loads.

  4. Provide Proper Power: Ensure the external 24VAC/VDC power supply is adequately sized to power the module itself plus any connected devices it supplies (e.g., sensors).

  5. Software Configuration is Mandatory: The module must be added to the controller’s configuration in the engineering software (e.g., Workbench), and each I/O point must be defined and mapped for it to function.
