Product Description
HONEYWELL 05701-A-0330 is a versatile analog input module from Honeywell’s Series 5701 I/O family, engineered to support multi-type signal acquisition—including 4-20mA current, 0-10V voltage, thermocouple, and RTD signals—in industrial applications such as chemical processing, oil & gas, and manufacturing. HONEYWELL 05701-A-0330 features 8 isolated channels, each independently configurable for different signal types via software and DIP switches, eliminating the need for multiple dedicated input modules and reducing hardware complexity. HONEYWELL 05701-A-0330 delivers high accuracy and stability across all supported signals, with built-in cold-junction compensation (for thermocouples) and lead wire compensation (for RTDs) to ensure reliable measurements. Additionally, HONEYWELL 05701-A-0330 supports hot-swappable installation and seamless integration with Honeywell’s control systems (Experion PKS, ControlEdge PLC) and third-party platforms via Modbus, making it a flexible solution for mixed-signal industrial environments. As a multi-function analog input component of Honeywell’s I/O portfolio, HONEYWELL 05701-A-0330 provides unified signal acquisition to streamline process control and monitoring.
Product Parameters
- Brand/Model: HONEYWELL 05701-A-0330
- Core Input Parameters
- Number of Channels: 8 isolated single-ended analog input channels (independently configurable)
- Supported Signals:
- Current: 4-20mA DC (0-24mA configurable)
- Voltage: 0-10V DC, -10V to +10V DC (bipolar)
- Thermocouple: J/K/T/E/R/S/B/N (with cold-junction compensation)
- RTD: Pt100, Pt1000 (2/3/4-wire configurations)
- Resolution: 16-bit (all signal types)
- Accuracy:
- 4-20mA/0-10V: ±0.02% full scale (20°C)
- Thermocouple: ±0.5°C (0-1000°C)
- RTD: ±0.2°C (0-600°C)
- Isolation: Channel-to-channel isolation (1500V AC), channel-to-ground isolation (2500V AC)
- System & Diagnostic Parameters
- Compatible Systems: Honeywell Experion PKS, ControlEdge PLC, Series 9000 RTU, third-party PLC/DCS (Modbus RTU/TC)
- Diagnostic Functions: Open/short circuit detection, overrange/underrange alerts, cold-junction failure (thermocouple), lead wire compensation failure (RTD), self-test
- Configuration: DIP switches (signal type/range) + software (Honeywell Engineering Tools)
- Environmental & Physical Parameters
- Operating Temperature: -40°C ~ +70°C
- Storage Temperature: -40°C ~ +85°C
- Vibration Resistance: 5g (10-2000Hz, IEC 60068-2-6 standard)
- Shock Resistance: 30g (11ms half-sine wave)
- Power Supply: 24V DC (18-32V) ±10%, power consumption ≤ 12W
- Protection Grade: IP20 (cabinet installation)
- Installation Method: DIN 35mm rail mounting (panel-mount optional)
- Dimensions: 120mm × 70mm × 30mm (compact DIN-rail form factor)
Advantages & Features
- Multi-Signal Flexibility: Each channel of HONEYWELL 05701-A-0330 can be configured for 4-20mA, 0-10V, thermocouple, or RTD signals, making it ideal for mixed-signal industrial environments (e.g., plants with pressure, temperature, and level sensors of different types).
- High Accuracy Across All Signals: 16-bit resolution and tight accuracy tolerances ensure reliable measurements for every supported signal type, with built-in compensation features (cold-junction, lead wire) eliminating common sources of error.
- Comprehensive Diagnostics: Real-time alerts for sensor faults, signal errors, and compensation failures enable proactive maintenance, reducing unplanned downtime and ensuring process safety.
- Hot-Swap & Wide Compatibility: The module supports hot-swappable replacement and integrates with Honeywell and third-party control systems via Modbus, simplifying installation and retrofits in existing infrastructure.
Application Fields & Cases
- Chemical Plant Multi-Parameter Monitoring: A petrochemical plant deployed HONEYWELL 05701-A-0330 modules to monitor reactor pressure (4-20mA), temperature (K-type thermocouple), level (0-10V), and jacket temperature (Pt100 RTD) with a single module. This reduced hardware count by 60% compared to using dedicated input modules for each signal type.
- Oil & Gas Production Facility: An onshore oil production site used HONEYWELL 05701-A-0330 to acquire signals from wellhead flow meters (4-20mA), pipeline temperature sensors (Pt100 RTD), and pressure transmitters (0-10V) in remote RTU cabinets. The module’s wide temperature range (-40°C to +70°C) ensured reliable operation in extreme weather.
- Food & Beverage Processing Line: A beverage manufacturer integrated HONEYWELL 05701-A-0330 into its ControlEdge PLC system to monitor mixing tank level (4-20mA), temperature (J-type thermocouple), and pH (0-10V) during production. The module’s accuracy enabled precise process control, improving product consistency.
Competitor Comparison
| Comparison Dimension | HONEYWELL 05701-A-0330 | Competitor 1 (Siemens SM 334 AI/AO Module) | Competitor 2 (Allen-Bradley 1734-IE8C) |
|---|---|---|---|
| Number of Channels | 8 (multi-signal) | 4 AI/2 AO (multi-signal) | 8 (analog only, fixed signal type) |
| Supported Signals | 4-20mA/0-10V/thermocouple/RTD | 4-20mA/0-10V/thermocouple | 4-20mA/0-10V |
| Accuracy (4-20mA) | ±0.02% full scale | ±0.05% full scale | ±0.03% full scale |
| Isolation (Channel-Channel) | 1500V AC | 500V AC | 1500V AC |
| Core Advantages | Multi-signal flexibility, 8 channels | Combined AI/AO functionality | High channel density (fixed signal) |
Selection Suggestions & Precautions
- Selection Suggestions: HONEYWELL 05701-A-0330 is ideal for users requiring multi-signal analog input (4-20mA/0-10V/thermocouple/RTD) in a single module (e.g., chemical plants, oil & gas facilities with mixed sensors). For Siemens TIA users, SM 334 AI/AO Module is preferred (note: fewer channels, combined AI/AO); Allen-Bradley 1734-IE8C suits Rockwell systems (fixed analog signals only).
- Precautions:
- Configure each channel’s signal type/range via DIP switches and software before installation—incorrect settings will cause measurement errors or failed compensation (e.g., cold-junction for thermocouples).
- Use signal-specific wiring best practices: shielded twisted-pair for 4-20mA/0-10V, thermocouple-grade extension cables for thermocouples, and matched-gauge wires for 4-wire RTDs.
- Ensure proper grounding of the module and sensors to prevent ground loops, which can corrupt low-voltage/thermocouple/RTD signals.
- Perform annual calibration (per Honeywell recommendations) for all signal types to maintain accuracy, especially in regulated industries (e.g., food processing, pharmaceutical manufacturing).
- Verify the module’s IP20 rating—install only in enclosed control cabinets to protect against dust and moisture.
