HITACHI LPU100H

Product Description

The HITACHI LPU100H is a CPU module belonging to Hitachi’s well-regarded PLC series, which has been widely adopted across Asian manufacturing sectors and increasingly in global markets. This specific model, HITACHI LPU100H, is engineered to provide fast logic execution, comprehensive instruction sets, and flexible communication capabilities. The unit features a built-in power supply and I/O interface, making it suitable for standalone machine control or as part of a larger distributed control system. Known for its exceptional reliability in continuous operation environments, the HITACHI LPU100H incorporates Hitachi’s proprietary noise suppression technology, ensuring stable performance even in electrically noisy industrial settings. For facilities requiring dependable control solutions with a proven track record, the HITACHI LPU100H represents a solid choice.

Technical Parameters

• Model Number: HITACHI LPU100H

• Series: Hitachi LPU Series (Micro to Mid-Range PLC)

• Processor Type: Dedicated CPU with high-speed logic execution

• Program Memory: Typically 8K to 16K steps (expandable depending on configuration)

• I/O Capacity: Expandable up to 256 to 512 I/O points (with expansion modules)

• Built-in I/O: Digital inputs and outputs integrated into the base unit

• Programming Language: Ladder Diagram (LD) with Hitachi proprietary instruction set

• Communication Ports: RS-232C (programming port), optional RS-485/422 for networking

• Scan Time: Approximately 1.5–2.5 ms per 1K steps

• Mounting: DIN-rail or panel mount

Advantages & Features

• Compact Integration: The HITACHI LPU100H combines CPU, power supply, and basic I/O in a single unit, significantly reducing panel space requirements compared to modular systems requiring separate components.

• Exceptional Noise Immunity: Hitachi’s proprietary design incorporates advanced filtering and isolation technology. The HITACHI LPU100H is specifically tested to withstand the high electromagnetic interference common in welding, motor control, and inverter-driven applications, ensuring uninterrupted operation.

• User-Friendly Programming: The HITACHI LPU100H supports a straightforward ladder logic environment with extensive documentation features, allowing maintenance technicians to troubleshoot efficiently without specialized training.

• Built-in Diagnostics: The CPU features comprehensive self-diagnostics, including watchdog timer, memory verification, and communication error detection, with LED status indicators for rapid fault identification.

• Cost-Effective Solution: As a mid-range controller, the HITACHI LPU100H offers an optimal balance of performance and affordability, making it particularly attractive for OEM machine builders requiring consistent, reliable control at competitive pricing.

Application Cases & Fields

The HITACHI LPU100H is extensively deployed across industries where compact, reliable control is essential:

• Packaging Machinery: Used in vertical form-fill-seal machines, cartoners, and labeling equipment, where the HITACHI LPU100H provides precise timing and sequencing for high-speed packaging lines.

• Plastics & Injection Molding: Deployed in injection molding machines and auxiliary equipment (dryers, conveyors, temperature controllers), leveraging the noise immunity of the HITACHI LPU100H in environments with heavy motor loads and VFDs.

• Semiconductor Manufacturing: Utilized in wafer handling equipment and process support systems, where the compact footprint and reliability of the HITACHI LPU100H are critical for cleanroom installations.

• HVAC & Building Automation: Installed in large-scale commercial and industrial HVAC systems for air handling unit control, chiller sequencing, and energy management applications.

Comparison with Competing Products

When compared to similar PLC CPU units from other manufacturers, the HITACHI LPU100H offers distinct advantages within its market segment:

• vs. Mitsubishi FX Series: While the Mitsubishi FX series dominates the Asian market, the HITACHI LPU100H often provides superior noise immunity in heavy industrial environments. The HITACHI LPU100H is frequently preferred in welding and metal fabrication applications where electrical noise can cause communication errors in other brands. Additionally, the HITACHI LPU100H typically offers a more cost-effective entry point for applications requiring basic to mid-range I/O counts.

• vs. Omron CP1 Series: The Omron CP1 series offers excellent networking capabilities. However, the HITACHI LPU100H is often selected for its simpler programming environment and lower total cost of ownership for standalone machine control. Facilities with existing Hitachi infrastructure find the HITACHI LPU100H provides seamless backward compatibility with legacy systems.

• vs. Siemens S7-1200: The Siemens S7-1200 offers advanced features like web servers and integrated PID. The HITACHI LPU100H competes by offering superior value in applications where advanced networking is not required, focusing instead on core control reliability and straightforward maintenance. For OEMs prioritizing simplicity and cost-effectiveness, the HITACHI LPU100H presents a compelling alternative.

Selection Suggestions & Precautions

When selecting the HITACHI LPU100H for your system, consider the following:

1. Verify I/O Requirements: The HITACHI LPU100H has a fixed number of built-in I/O points. Ensure that your application’s I/O count does not exceed the base unit capacity, or confirm that you have a clear expansion plan using Hitachi-compatible expansion modules. Exceeding I/O capacity will require upgrading to a larger CPU model.

2. Confirm Programming Software Compatibility: Programming the HITACHI LPU100H requires Hitachi-specific software (typically Pro-H or similar). Verify that your software version supports this specific CPU model. Using incompatible software versions may prevent proper communication or limit access to advanced instructions.

3. Power Supply Considerations: While the HITACHI LPU100H includes an integrated power supply, verify that the total current draw from connected expansion modules and field devices does not exceed the capacity of the built-in supply. Overloading the power supply can cause intermittent operation or complete system failure.

4. Communication Protocol Verification: If the HITACHI LPU100H needs to communicate with SCADA systems, HMIs, or other PLCs, confirm that the built-in communication ports (RS-232C, optional RS-485) support the required protocols. For Ethernet-based networking, verify whether an expansion module is required, as the base HITACHI LPU100H does not include native Ethernet.

5. Environmental & Mounting: The HITACHI LPU100H is designed for industrial environments but should be installed within a properly rated enclosure. Ensure adequate clearance around the unit for heat dissipation and cable routing. Do not install in areas with condensing humidity or exposure to aggressive chemicals without appropriate protective measures.
