Description
Product Description
HIMA F3232 is a high-density digital input module engineered for HIMA’s HIMatrix safety instrumented system (SIS), designed to deliver reliable signal acquisition for safety-critical industrial applications including oil & gas processing, chemical manufacturing, and power generation. HIMA F3232 integrates 16 isolated digital input channels with ultra-fast response capabilities, enabling real-time monitoring of field sensors (e.g., emergency stop buttons, pressure switches, flow switches) to trigger safety interlock logic. HIMA F3232 is certified to IEC 61508 SIL 3 and complies with ATEX/IECEx standards for hazardous environments, ensuring fail-safe operation even in explosive atmospheres. Additionally, HIMA F3232 features advanced diagnostic functions and hot-swappable installation, minimizing maintenance downtime and enhancing the availability of critical control systems. As a key component of HIMA’s HIMatrix portfolio, HIMA F3232 combines high channel density with robust performance to meet the demands of large-scale safety applications.
Product Parameters
- Brand/Model: HIMA F3232
- Core Input Parameters
- Number of Channels: 16 isolated digital input channels (2 channels per isolation group)
- Input Voltage: 24V DC (18-30V DC operating range)
- Input Type: Sinking (NPN) or sourcing (PNP) configurable per channel
- Response Time: ≤1ms (unfiltered), up to 100ms (software-filterable for noise suppression)
- Isolation: Channel-to-group isolation (1500V AC), module-to-backplane isolation (2500V AC)
- System & Diagnostic Parameters
- Compatible Systems: HIMA HIMatrix F3/F4, HIMA Safety Manager
- Diagnostic Functions: Channel short/open circuit detection, overvoltage/undervoltage monitoring, backplane communication diagnostics
- Communication Protocol: HIMA proprietary SafetyBUS p, Ethernet/IP (optional)
- Configuration Software: HIMA SILworX V3.0+
- Environmental & Physical Parameters
- Operating Temperature: -40°C ~ +70°C
- Storage Temperature: -40°C ~ +85°C
- Vibration Resistance: 15g (10-2000Hz, IEC 60068-2-6 standard)
- Shock Resistance: 50g (11ms half-sine wave)
- Power Supply: 24V DC (redundant input supported), power consumption ≤ 5W
- Protection Grade: IP20 (cabinet installation), IP65 (optional ruggedized enclosure)
- Installation Method: HIMA HIMatrix standard rack slot or DIN 35mm rail mounting
- Dimensions: 120mm × 80mm × 40mm
Advantages & Features
- High-Density Channel Integration: HIMA F3232 packs 16 digital input channels into a compact module, reducing the number of components required for large-scale SIS and optimizing cabinet space. This high density lowers installation costs and simplifies system wiring for applications with numerous field sensors.
- Ultra-Fast Response & SIL 3 Compliance: With a ≤1ms unfiltered response time and IEC 61508 SIL 3 certification, HIMA F3232 ensures rapid detection of critical process anomalies and reliable execution of safety interlocks—essential for preventing accidents in high-risk environments like refineries and chemical plants.
- Advanced Diagnostics & Fault Detection: HIMA F3232 provides real-time diagnostics for channel faults (short/open circuits), voltage irregularities, and communication issues, sending alerts to the SIS controller for immediate action. This predictive capability reduces unplanned downtime by identifying potential failures before they impact system operation.
- Hazardous Environment Compatibility: ATEX/IECEx certification allows HIMA F3232 to operate in Zone 2/22 explosive atmospheres, while its wide temperature range (-40°C ~ +70°C) and vibration resistance make it suitable for harsh industrial environments including offshore platforms and desert power plants.
Application Fields & Cases
- Oil Refinery Crude Distillation Unit SIS: A major oil refinery deployed HIMA F3232 modules in its HIMatrix SIS to monitor 128 field sensors (pressure, temperature, level) across its crude distillation unit. The high-density channels reduced the number of modules needed by 50%, while the 1ms response time triggered emergency shutdowns for pressure spikes, preventing equipment damage and environmental spills.
- Chemical Plant Batch Reactor Safety System: A specialty chemical manufacturer integrated HIMA F3232 into its reactor safety system, using the module to monitor emergency stop buttons, valve position sensors, and gas detection devices. The ATEX certification ensured compliance with hazardous environment regulations, and diagnostics identified a faulty level sensor channel before it caused a false reactor shutdown.
- Power Plant Turbine Protection: A combined-cycle power plant used HIMA F3232 to monitor vibration switches, oil pressure sensors, and flame detectors for its gas turbines. The module’s vibration resistance (15g) and wide temperature range ensured reliable operation in the turbine enclosure, while hot-swappable design allowed maintenance during peak power generation hours.
Competitor Comparison
| Comparison Dimension | HIMA F3232 | Competitor 1 (Triconex 3501E) | Competitor 2 (Siemens S7-400F DI Module) |
|---|---|---|---|
| Number of Channels | 16 | 16 | 32 |
| Response Time | ≤1ms (unfiltered) | ≤2ms | ≤5ms |
| SIL Certification | SIL 3 | SIL 3 | SIL 2 |
| Hazardous Environment Cert | ATEX/IECEx | ATEX/IECEx | Optional |
| Vibration Resistance | 15g | 5g | 5g |
| Core Advantages | High density, ultra-fast response, ATEX compliance | TMR redundancy integration | Siemens TIA portal compatibility |
Selection Suggestions & Precautions
- Selection Suggestions: HIMA F3232 is ideal for HIMA HIMatrix users requiring high-density, SIL 3-certified digital inputs for large-scale safety systems (e.g., refineries, chemical plants). For applications with 8 channels, HIMA F3221 is recommended. Non-HIMA system users may prefer Triconex 3501E for TMR redundancy or Siemens S7-400F for PROFINET integration.
- Precautions:
- Configure input type (NPN/PNP) and response time filters per sensor requirements to avoid signal delays or false triggers.
- Use shielded, intrinsically safe cables in hazardous environments to maintain ATEX/IECEx compliance and minimize EMI interference.
- Perform quarterly diagnostic checks via SILworX software to verify channel integrity and replace degraded components proactively.
- Ensure redundant power supplies are connected to independent sources to maximize system availability.
- Avoid exceeding the module’s voltage range (18-30V DC) to prevent permanent damage to input channels.
