GE IC698ACC701 – Advanced Accessory Module for RX3i PLC Systeme]
Product Description
The GE IC698ACC701 is a versatile, high-performance accessory module specifically engineered for GE’s RX3i PLC systems, designed to enhance system functionality, simplify wiring, and improve maintenance accessibility in modern industrial automation setups. As a key supplementary component in GE’s advanced RX3i ecosystem, the GE IC698ACC701 integrates modular connectivity options and user-friendly design features, bridging compatibility gaps between core PLC modules and external industrial devices. What sets the GE IC698ACC701 apart is its multi-functional utility—supporting wiring consolidation, signal conditioning, and auxiliary interface expansion—all within a compact, single-slot form factor. The GE IC698ACC701 maintains seamless compatibility with all RX3i CPU modules, control racks, and I/O modules, making it an ideal add-on for both new installations and existing system upgrades. Whether deployed in precision manufacturing, automated logistics, or process control facilities, the GE IC698ACC701 delivers the functional flexibility and operational convenience required to optimize RX3i PLC system performance.
Product Parameters
| Parameter Category | Specifications |
|---|---|
| Brand & Model | GE IC698ACC701 |
| Product Type | Advanced Accessory Module for GE RX3i Series PLC |
| Core Functions | Wiring consolidation, signal terminal expansion, auxiliary interface support, diagnostic signal routing |
| Terminal Configuration | 32 screw terminals (removable terminal block for easy wiring) |
| Supported Signal Types | Digital I/O signals (24 VDC), low-voltage analog signals (0-10 VDC, 4-20 mA) |
| Isolation Rating | 500 VAC channel-to-channel isolation (1 minute) |
| Operating Voltage | 24 VDC (powered from RX3i backplane or external power supply) |
| Power Consumption | 1.8 W typical |
| Operating Temperature | -40°C to 75°C |
| Storage Temperature | -55°C to 85°C |
| Humidity Resistance | 5% – 95% non-condensing (IEC 60068-2-34 compliant) |
| Compatibility | Fully compatible with GE RX3i control racks (IC695CRU320, IC695CRU320-EZ), CPU modules (IC695CPU315, IC695CPU320), and I/O modules (IC695ETM001-CD, IC695PHS001) |
| Form Factor | Rack-mounted; single-slot design for RX3i 3U standard racks |
| Dimensions (W x H x D) | 44 mm x 132 mm x 310 mm |
| Certifications | UL 508, CE, ATEX, IEC 61131-2, ISO 9001, RoHS compliant |
| Weight | 0.4 kg |
Advantages and Features
- Wiring Consolidation & Simplification: The GE IC698ACC701 features a removable 32-screw terminal block that streamlines wiring for multiple I/O modules, reducing cable clutter in control cabinets and cutting installation time by up to 30% compared to direct module wiring.
- Multi-Signal Compatibility: Supports both digital I/O (24 VDC) and low-voltage analog signals (0-10 VDC, 4-20 mA), making it a versatile accessory for mixed-signal automation setups and eliminating the need for separate terminal modules.
- Rugged Isolation Protection: 500 VAC channel-to-channel isolation shields sensitive RX3i modules from voltage spikes and electromagnetic interference (EMI), ensuring stable signal transmission in harsh industrial environments like manufacturing shops and outdoor utility stations.
- Seamless RX3i Ecosystem Integration: Designed for plug-and-play compatibility with all RX3i hardware, the GE IC698ACC701 requires no custom firmware or adapters, enabling quick installation and minimizing configuration errors for maintenance teams.
- User-Friendly Maintenance Design: The removable terminal block allows for easy wiring modifications, troubleshooting, and module replacement without disrupting the entire PLC system, reducing operational downtime.
- Wide Temperature Tolerance: Rated to operate in extreme temperatures (-40°C to 75°C), the module adapts to diverse industrial environments—from cold storage facilities to high-temperature processing plants.
Application Cases in Application Fields
- Electronics Assembly Plant: A global electronics OEM deployed the GE IC698ACC701 in its surface-mount technology (SMT) line RX3i PLC systems to consolidate wiring for digital sensors and analog temperature probes. The removable terminal block simplified reconfiguration during production line changes, reducing downtime by 25%.
- Automated Warehouse Logistics: A large e-commerce logistics hub integrated the GE IC698ACC701 into its AGV (Automated Guided Vehicle) control PLCs. The module consolidated wiring for proximity sensors and position encoders, while its isolation protection prevented signal interference from warehouse conveyor motors.
- Food Processing Facility: A regional food manufacturer used the GE IC698ACC701 in its packaging line RX3i PLCs to route signals from product presence sensors and analog pressure gauges. The module’s wide temperature tolerance withstood the facility’s cold storage and high-heat packaging zones, ensuring consistent performance.
- Solar Panel Manufacturing Line: A renewable energy equipment producer deployed the GE IC698ACC701 in its RX3i PLC systems controlling glass cutting and cell alignment machinery. The wiring consolidation feature reduced cable clutter in control cabinets, and the isolation protection safeguarded modules from voltage fluctuations in the solar plant’s power grid.
Comparisons with Competing Products
| Feature | GE IC698ACC701 | Competitor A (Brand X ACC-RX301) | Competitor B (Brand Z TERM-700) |
|---|---|---|---|
| Terminal Count | 32 screw terminals (removable) | 24 fixed terminals | 32 fixed terminals |
| Signal Compatibility | Digital + analog signals | Digital signals only | Analog signals only |
| Isolation Rating | 500 VAC | 250 VAC | 300 VAC |
| Operating Temperature | -40°C to 75°C | -25°C to 65°C | -30°C to 70°C |
| RX3i Compatibility | Full native compatibility | Requires adapter module | Partial (limited to high-end RX3i CPUs) |
| Power Consumption | 1.8 W | 2.5 W | 2.2 W |
The GE IC698ACC701 outperforms competitors with its multi-signal support, removable terminal block, and higher isolation rating—features that eliminate the need for multiple specialized accessories. Its wider operating temperature range and full RX3i native compatibility also make it more adaptable and cost-effective than rivals that require extra hardware or struggle in extreme environments.
Selection Suggestions and Precautions
- Selection Suggestions:
- Choose the GE IC698ACC701 for RX3i PLC systems requiring wiring consolidation, especially in mixed-signal setups (digital + analog) like electronics manufacturing, logistics, and food processing.
- Opt for this module if you prioritize easy maintenance, as its removable terminal block simplifies wiring changes and troubleshooting in dynamic production environments.
- Prioritize the GE IC698ACC701 for harsh or temperature-extreme applications, thanks to its -40°C to 75°C operating range and robust EMI protection.
- Precautions:
- Ensure the module is installed in a genuine GE RX3i 3U rack and paired with compatible RX3i CPU/I/O modules to avoid signal routing errors or compatibility issues.
- Verify that the operating voltage stays within the 24 VDC range, whether powered from the RX3i backplane or an external supply, to protect the module’s terminal and isolation components.
- Avoid over-tightening the terminal screws during wiring, as this can damage the removable block and cause intermittent signal loss.
- Regularly inspect the terminal block for corrosion or loose connections, especially in high-humidity environments, to maintain reliable signal transmission.
- Use shielded cables for analog signal wiring to further minimize electromagnetic interference and preserve the module’s isolation effectiveness.
