GE IC695CPE330-AAAB – Comprehensive PLC High-Performance Processor Module Introduction

Product Description

Product Parameters

1. Product Model: GE IC695CPE330-AAAB
2. Module Type: High-performance PLC processor module (GE RX3i PLC compatible)
3. Core Processor: 32-bit dual-core microprocessor, clock frequency up to 900 MHz
4. Program Memory: 3 MB on-board Flash memory (expandable up to 12 MB via memory modules)
5. Data Memory: 1.5 MB RAM (with single battery backup for critical data retention)
6. Instruction Execution Speed: 0.04 microseconds per basic instruction
7. I/O Capacity: Supports up to 49,152 digital I/O points and 6,144 analog I/O points
8. Built-in Communication Ports: 1 x RS-232 serial port, 1 x USB 2.0 port, 1 x 10/100 Ethernet port (for programming & diagnostics)
9. Operating Voltage: DC 5V (powered by PLC backplane)
10. Operating Temperature Range: 0°C to 60°C
11. Mechanical Dimensions: 102mm × 152mm × 89mm (length × width × height)
12. Certifications: CE, UL listed, RoHS compliant

Advantages and Features

1. High-Speed Dual-Core Processing: GE IC695CPE330-AAAB is equipped with a 900 MHz dual-core processor, executing basic instructions in just 0.04 microseconds, which meets the demands of high-speed automation processes such as robotic assembly, continuous production lines, and precision machining.
2. Expandable Memory for Complex Tasks: With 3 MB on-board Flash memory (expandable to 12 MB) and 1.5 MB battery-backed RAM, GE IC695CPE330-AAAB provides ample storage for complex control programs, large datasets, and process logs, while ensuring critical data is preserved during unexpected power outages.
3. Scalable I/O Capacity for Large Systems: Supporting up to 49,152 digital and 6,144 analog I/O points, GE IC695CPE330-AAAB scales seamlessly to fit small standalone machines and large distributed automation systems alike, eliminating the need for multiple processors and reducing system complexity.
4. Multi-Port Communication for Easy Maintenance: The built-in Ethernet, USB 2.0, and RS-232 ports enable fast connection to programming software, diagnostic tools, and upper-level systems, streamlining program development, on-site debugging, and routine maintenance.
5. Seamless RX3i Ecosystem Compatibility: Tailored exclusively for GE RX3i PLC chassis, GE IC695CPE330-AAAB integrates flawlessly with all RX3i I/O, communication, and specialty modules, reducing compatibility risks and shortening system deployment time.

Application Cases in Application Fields

1. Automotive Component Manufacturing: A leading European automotive parts factory integrated GE IC695CPE330-AAAB into its engine assembly line. The processor coordinated 25 robotic arms, 8,000 digital I/O points, and 2,000 analog sensors, reducing assembly errors by 28% and increasing production throughput by 22%.
2. Water Treatment Plant Automation: A North American municipal water treatment facility deployed GE IC695CPE330-AAAB to control its purification and distribution systems. The module’s I/O capacity managed 5,000 digital actuators (pumps, valves) and 1,500 analog sensors (pH, turbidity), improving water quality consistency by 18% and reducing energy consumption by 15%.
3. Food & Beverage Bulk Production: An Asian beverage manufacturer adopted GE IC695CPE330-AAAB in its large-scale bottling plant. The processor’s fast instruction speed synchronized filling, capping, labeling, and packaging processes, increasing line throughput by 26% and cutting product waste by 19%.
4. Renewable Energy Farm Control: A global renewable energy company used GE IC695CPE330-AAAB to manage its solar panel farm. The processor collected data from 12,000 remote I/O points (solar trackers, inverters), enabling real-time performance monitoring and optimizing energy output by 20%.

Comparisons with Competing Products

Selection Suggestions and Precautions

Selection Suggestions

1. Match GE RX3i Ecosystem: Prioritize GE IC695CPE330-AAAB if your existing system uses GE RX3i PLCs, as it guarantees seamless integration with RX3i modules and maximizes the value of your current hardware investment.
2. Assess Mid-to-Large Scale Automation Needs: Choose GE IC695CPE330-AAAB for applications requiring moderate-to-high I/O capacity and processing speed, such as automotive assembly lines, water treatment plants, and bulk production facilities.
3. Prioritize Easy Maintenance: Opt for GE IC695CPE330-AAAB if on-site debugging and program updates are frequent, as its multi-port communication design simplifies these routine tasks and reduces downtime.
4. Evaluate North American Market Compliance: Select GE IC695CPE330-AAAB for deployments in North America, thanks to its UL certification that meets local industrial safety requirements.

Precautions

1. Battery Maintenance: Regularly check and replace the backup battery of GE IC695CPE330-AAAB (recommended every 2–3 years) to ensure critical data retention during power outages.
2. Backplane Power Stability: Ensure the RX3i chassis provides stable DC 5V power to GE IC695CPE330-AAAB, as voltage fluctuations can cause processor malfunctions or program corruption.
3. Program Backup Routine: Implement regular backups of the control program and data stored in GE IC695CPE330-AAAB to external storage, preventing loss from unexpected module failures or firmware errors.
4. Anti-Static Handling: Use anti-static gloves when installing or removing GE IC695CPE330-AAAB, as electrostatic discharge can damage the processor’s internal microcomponents and lead to permanent failure.
