Description
Product Description
The GE HE700GEN200, detailed further here, is a legacy general-purpose AC input module from the GE Fanuc Series 90-30 PLC family. This module serves as a critical interface, allowing the PLC to monitor the state of field devices that operate on alternating current, such as proximity switches, pushbuttons, and contactor auxiliaries. The primary function of the GE HE700GEN200 is to convert high-voltage AC signals from the industrial field (typically 120V AC) into isolated, low-voltage logic-level signals that the PLC’s CPU can safely process. In a typical 90-30 rack, this module provides reliable digital input sensing, which is fundamental for sequencing, control, and safety interlock logic. For maintenance technicians and system integrators supporting older but vital automation infrastructure, understanding the specifications and sourcing authentic replacements for the HE700GEN200 is key to sustaining operational uptime.
Product Parameters
-
Manufacturer: GE (General Electric), formerly GE Fanuc Automation.
-
Series: Series 90-30 PLC.
-
Module Type: Discrete AC Input Module.
-
Part Number: HE700GEN200
-
Input Voltage: 120V AC.
-
Number of Points: 16 points (isolated in groups, typically 8 points per common).
-
Input Current: Typically ~10-15 mA per point at rated voltage.
-
On-State Voltage Range: A specified range (e.g., 79-132V AC) where the input is reliably recognized as ON.
-
Isolation: Optical isolation between field input circuits and the PLC’s internal logic.
-
Backplane Current: The amount of 5V DC current drawn from the PLC rack’s power supply (e.g., 80 mA).
-
Status Indicators: LED indicator for each input point to show ON/OFF status.
Advantages and Features
-
Robust and Proven Design: As part of the widely adopted Series 90-30, this module is known for its durability and reliability in harsh industrial environments.
-
High-Voltage Interface: Directly interfaces with common 120V AC control circuits without the need for external signal converters, simplifying cabinet design.
-
Optical Isolation: Provides excellent noise immunity and protects the sensitive PLC electronics from voltage spikes and transients present on the field wiring.
-
Clear Diagnostic Indicators: Individual LEDs for each channel enable quick troubleshooting of field device issues directly at the module.
-
Easy Integration: Plug-and-play compatibility with any Series 90-30 rack; configuration is handled automatically by the PLC CPU.
Application Cases in Application Fields
-
Material Handling & Conveyor Systems: Used to monitor the status of limit switches, presence sensors, and manual control stations that operate on plant-wide 120V AC control voltage.
-
Packaging Machinery: Interfaces with AC-powered photoelectric sensors and safety gate switches to control machine cycles and ensure operator safety.
-
Legacy Automotive Manufacturing Lines: A common component in older transfer line and assembly station controls, where the GE HE700GEN200 reads signals from tooling clamps and part detectors.
-
Building Management Systems: In older HVAC control panels, it might be used to monitor status feedback from pumps, fans, and alarms wired to 120V AC.
Comparisons with Competing Products
Compared to contemporary modules from Allen-Bradley (SLC 500 1746-IA16) or Siemens (SIMATIC S7-300 SM 321), and even modern equivalents, the GE HE700GEN200 has specific distinctions:
-
Era-Specific Technology: It represents a mature, 24-30 year old technology. Modern equivalents often offer higher density (32 points), universal AC/DC voltage compatibility, and more advanced diagnostics via software.
-
Platform Longevity: The Series 90-30 platform is in a legacy/sustained phase. Competitors’ platforms like the Allen-Bradley SLC 500 are also legacy, while Siemens S7-300 has a more recent successor. Direct replacement modules are largely sourced from the aftermarket.
-
Cost & Availability: New-old-stock or refurbished HE700GEN200 modules can be expensive due to scarcity. Modern PLCs using newer input cards may offer a lower total cost for new projects but require a complete system overhaul.
-
Software Integration: It is configured with legacy software (VersaPro, Proficy Machine Edition Logic Developer), which differs from the current software ecosystems of major brands.
Selection Suggestions and Precautions
-
Verify Exact Replacement Need: Confirm the specific part number HE700GEN200 from the existing module’s label. The Series 90-30 had other AC input modules (e.g., different voltages like 24V AC or 240V AC with different part numbers).
-
Assess System Health: When replacing a failed module, investigate the root cause. A failed GE HE700GEN200 can sometimes be a symptom of external problems like chronic overvoltage, poor wiring, or a failing field device damaging the input circuit.
-
Consider Migration Planning: For critical systems, evaluate a long-term plan to migrate from the Series 90-30 platform to a modern PLC (like GE’s RX3i or Emerson’s PACSystems). Continual reliance on legacy spares carries future risk.
-
Source from Reputable Suppliers: Due to its legacy status, procure from specialized industrial automation suppliers with a proven track record, such as the source linked here, to ensure you receive a tested, functional unit with a warranty. Beware of counterfeit or heavily worn components.
