GE DS200ACNAG1ADD

Description

Product Description

Product Parameters

Advantages and Features

1. Multi-Protocol Compatibility: GE DS200ACNAG1ADD supports a full range of mainstream industrial communication protocols including Ethernet/IP, MODBUS TCP, and PROFINET IO, enabling seamless connection with diverse on-site devices such as sensors, actuators, and upper monitoring systems, significantly reducing system integration complexity.
2. High-Speed Data Transmission: Equipped with Gigabit Ethernet ports, the module achieves a maximum transmission rate of 1000 Mbps, ensuring low-latency and low-packet-loss data exchange even in scenarios with large concurrent data volumes, meeting the real-time requirements of high-speed production lines.
3. Dual-Port Redundancy Design: The two adaptive Ethernet ports support network redundancy and daisy-chain topology, eliminating single points of failure and enhancing the reliability of industrial communication networks, which is crucial for continuous-production industries.
4. Robust Anti-Interference Performance: Adopting advanced EMC (Electromagnetic Compatibility) design and shielded circuit technology, GE DS200ACNAG1ADD effectively resists electromagnetic interference, voltage surges, and static electricity in harsh industrial environments, ensuring stable signal transmission.
5. Seamless System Integration: Tailor-made for GE’s Mark VIe and Mark VI control systems, the module requires no additional custom drivers. It can be quickly configured via GE’s dedicated programming software, streamlining commissioning and reducing project cycles.
6. Intuitive Maintenance Experience: Clear multi-functional status indicators and built-in diagnostic functions allow on-site technicians to quickly locate network faults such as link disconnections or protocol mismatches. The DIN rail mounting design also facilitates easy installation and replacement, minimizing downtime.
7. Wide Environmental Adaptability: With an operating temperature range of -40°C to +70°C, the module performs stably in extreme cold, high-temperature, and high-humidity conditions, making it suitable for automation projects in diverse geographical locations and working environments.

Application Fields and Cases

Application Fields

Application Cases

1. Power Generation Industry: A large coal-fired power plant integrated GE DS200ACNAG1ADD into its boiler and turbine control systems. The module connected 15 sets of sensors, 8 actuators, and 3 central monitoring computers via Ethernet/IP protocol, achieving real-time transmission of key parameters such as steam temperature and pressure. The data transmission delay was controlled within 5ms, reducing equipment failure rates by 20% and improving the plant’s operational efficiency.
2. Oil and Gas Industry: In an offshore oil drilling platform’s production control system, GE DS200ACNAG1ADD was deployed to establish a stable communication link between the on-site Mark VIe controller and the onshore monitoring center. Using MODBUS TCP protocol, it realized remote monitoring of drilling speed, well pressure, and other parameters. Its robust anti-interference performance ensured uninterrupted communication even in harsh marine environments, enhancing operational safety.
3. Metallurgical Industry: A large steel mill used GE DS200ACNAG1ADD to upgrade its continuous casting production line’s communication network. The module connected multiple PLC controllers, frequency converters, and temperature sensors through PROFINET IO protocol, realizing synchronous control of casting speed and mold temperature. The production line’s stability was improved by 25%, and the scrap rate was reduced by 18%.

Comparison with Competitors

Selection Suggestions and Precautions

Selection Suggestions

1. For projects using GE Mark VIe or Mark VI control systems that require multi-protocol communication and high-speed data transmission, GE DS200ACNAG1ADD is the optimal choice, ensuring perfect compatibility and stable communication performance.
2. Prioritize this module for industries with harsh operating environments (e.g., offshore oil platforms, metallurgical plants) or high requirements for network reliability (e.g., power plants, continuous production lines). Its dual-port redundancy and robust anti-interference capabilities can guarantee uninterrupted operation.
3. For retrofitting legacy GE control systems, GE DS200ACNAG1ADD is a cost-effective option, as it integrates seamlessly with existing hardware and software, avoiding the need for full system replacement and reducing upgrade costs.

Precautions

1. Install the module securely on a 35mm DIN rail and keep it away from high-power inverters, motors, and other strong electromagnetic interference sources. Use shielded Cat5e/Cat6 cables for Ethernet wiring and maintain a distance of at least 30cm from power cables.
2. Follow the product manual strictly for wiring, ensuring correct connection of Ethernet ports and RS485 terminals. Avoid exceeding the maximum communication distance to prevent signal attenuation or transmission failure.
3. Maintain the operating voltage within the range of 20.4V DC – 28.8V DC. It is recommended to use a stable power supply with surge protection to avoid voltage fluctuations affecting module performance.
4. Configure communication parameters (IP address, protocol type, baud rate) using GE’s dedicated software, ensuring consistency with on-site devices to prevent protocol mismatches and communication failures.
5. Conduct regular inspections of the module’s status indicators and network connections. Clean dust from the ports periodically and use the built-in diagnostic function to monitor communication status, addressing anomalies promptly to avoid fault expansion.
6. Store the module in a dry, well-ventilated, and vibration-free environment. Avoid exposure to direct sunlight, extreme temperatures, and corrosive gases. When replacing the module, back up configuration parameters first to ensure seamless system integration after replacement.
