GE 489-P5-LO-A20

¥999.00

Product Description

The GE 489-P5-LO-A20 is a versatile and feature-rich Generator Protection Relay from General Electric’s highly regarded 489 series. Designed specifically for the protection, metering, and monitoring of medium and small-sized generators, this relay combines comprehensive protective functions with advanced monitoring capabilities in a compact, field-proven package. Part of the Multilin product line, the 489-P5-LO-A20 is engineered to safeguard generators in various applications, from industrial cogeneration to standby power generation. It provides critical protection against electrical faults, abnormal operating conditions, and mechanical stresses, ensuring generator longevity and system stability. The flexible design of the GE 489-P5-LO-A20 allows it to be tailored to specific generator configurations, including synchronous, induction, and dual-fed rotating machines.

Category:

Description

Product Parameters and Specifications

The 489-P5-LO-A20 model number contains specific information about its configuration and capabilities. Below are the detailed specifications decoded from the part number:

  • Manufacturer: GE Multilin

  • Series: 489 Generator Protection Relay

  • Base Model: 489

  • Part Number: GE 489-P5-LO-A20

  • Product Type: Digital Generator Protection and Management Relay

  • Style Designation Breakdown:

    • P5: Power Supply and I/O Configuration

      • Power Supply: 20-60 VDC / 20-48 VAC (Nominal)

      • Digital Inputs: 8 Form-A (dry contacts)

      • Output Relays: 4 Form-C (electromechanical)

    • LO: Display and Communications

      • Display: Standard Vacuum Fluorescent Display (VFD) with keypad

      • Communications: RS485 port with Modbus RTU protocol

    • A20: CT Input Range

      • Phase CT Secondary: 5A nominal

      • Ground CT Secondary: 5A nominal (20A continuous rating)

  • Protection Elements: Includes overcurrent (50/51), voltage protection (27/59), frequency protection (81O/U), reverse power (32), differential protection (87), and thermal modeling.

  • Accuracy: Meets or exceeds IEC 255-11 and IEEE C37.90 standards for protection relay accuracy.

Advantages and Features

The GE 489-P5-LO-A20 offers a comprehensive suite of features that make it a preferred choice for generator protection:

  • Comprehensive Protection Suite: Integrates all essential generator protection functions in a single device, eliminating the need for multiple discrete relays. This includes mechanical protection through vibration and temperature monitoring inputs.

  • Advanced Metering and Monitoring: Provides real-time metering of voltages, currents, power (kW, kVAR, kVA), power factor, frequency, and energy measurements. The 489-P5-LO-A20 also tracks operational statistics like run hours and number of starts.

  • Flexible Oscillography and Event Recording: Captures waveform data and sequence-of-events records to aid in post-fault analysis and system troubleshooting, helping engineers quickly identify the root cause of disturbances.

  • Customizable Logic: Features FlexLogic™ programmable logic, allowing users to create custom protection and control schemes without additional hardware. This enables the GE 489-P5-LO-A20 to adapt to unique generator configurations and user-specific requirements.

  • Robust Communication Capabilities: The built-in RS485 port with Modbus RTU protocol allows seamless integration with plant SCADA systems, PLCs, and building management systems for remote monitoring and control.

  • User-Friendly Interface: The intuitive front-panel keypad and bright VFD display provide easy local access to all settings, measurements, and diagnostics without requiring a computer.

Application Fields and Cases

The 489-P5-LO-A20 is deployed across a wide spectrum of industries where generator protection is critical:

  • Industrial Cogeneration: Used in manufacturing plants, refineries, and chemical facilities where steam turbines or combustion turbines generate both electricity and process heat. The GE 489-P5-LO-A20 protects these generators while they operate in parallel with the utility grid.

  • Standby and Emergency Power: Installed in hospitals, data centers, and commercial buildings to protect diesel or gas generator sets that provide backup power during utility outages. The relay ensures the generator starts reliably and operates safely when called upon.

  • Renewable Energy: Applied in small hydroelectric plants and biomass power facilities to protect generators that may experience variable operating conditions due to changing resource availability.

  • Marine and Offshore: Used on ships and offshore platforms to protect onboard generator sets that serve as the primary power source for all vessel or platform operations.

Comparison with Competing Products

When evaluated against alternative generator protection relays, the GE 489-P5-LO-A20 demonstrates distinct strengths:

  • vs. SEL-700G: Both relays offer similar protection functions. However, the 489-P5-LO-A20 often provides a more intuitive programming environment with FlexLogic™ and a more straightforward user interface for operators accustomed to GE platforms. The SEL relay may offer more advanced synchronization features, but the GE unit typically presents a better cost-to-performance ratio for medium-sized generators.

  • vs. ABB REG670: The ABB REG670 is a more advanced, modular protection system suitable for large utility-scale generators. The GE 489-P5-LO-A20 is designed as a compact, self-contained solution for smaller generators, offering easier installation and configuration without the complexity and higher cost of a modular system. For applications from 0.5 MW to 50 MW, the 489-P5-LO-A20 is often the more practical and economical choice.

Selection Suggestions and Precautions

When specifying or purchasing the GE 489-P5-LO-A20, consider these important factors:

  • CT Sizing Verification: The “-A20” suffix indicates 5A secondary CTs. Ensure your existing current transformers match this rating. If your installation uses 1A CTs, a different variant (like -A10) would be required.

  • Power Supply Compatibility: Confirm that your control power matches the “P5” power supply rating (20-60 VDC / 20-48 VAC). Using incorrect voltage can damage the relay. For higher voltage stations (like 110-250 VDC), consider the 489-P1 variant instead.

  • Firmware Revision: Check the firmware version of the GE 489-P5-LO-A20 to ensure it supports all the protection functions required for your specific generator type. GE has released several firmware updates over the years that added new features.

  • Application-Specific Settings: Generator protection requires careful coordination with utility protection systems. Always have protection settings calculated and reviewed by a qualified protection engineer familiar with your local utility interconnection requirements.

  • Auxiliary Components: Consider whether you need additional components like a synchronization module or external annunciators, as these are not integrated into the 489-P5-LO-A20.
