BENTLY 136188-02

Description

1. Product Overview

2. Product Parameters

2.1 Core Communication Specifications

• Supported Protocols: Modbus TCP/IP, OPC UA, Ethernet/IP, PROFINET, Bently proprietary API
• Network Interfaces: 2× Gigabit Ethernet ports (RJ45), 1× fiber optic port (single-mode, optional), 1× RS-485
• Data Transfer Rate: Up to 1 Gbps (Ethernet), 100 Mbps (fiber)
• Latency: ≤30 ms (real-time data transmission)
• Redundancy: Dual Ethernet ports (failover mode), fiber redundancy (optional)

2.2 Electrical Parameters

• Power Supply: 24 VDC ±10% (powered via 3500 rack backplane)
• Power Consumption: ≤15 W
• Isolation: 2500 VAC between communication interfaces and backplane
• EMI/EMC Compliance: EN 61000-6-2 (industrial immunity), EN 61000-6-4 (industrial emissions)
• Cybersecurity Features: Firewall, access control lists (ACLs), OPC UA encryption, firmware authentication

2.3 Environmental & Mechanical Parameters

• Operating Temperature: -40°C to +85°C
• Storage Temperature: -55°C to +100°C
• Relative Humidity: 5%–95% (non-condensing, MIL-STD-810G compliant)
• Protection Rating: IP20 (rack-mounted); IP65 optional with rugged enclosure
• Mounting: Bently 3500 series chassis (1-slot width, 3U height)
• Dimensions: 170 mm × 125 mm × 48 mm (L×W×H)
• Weight: ~0.8 kg

2.4 Certification & Compatibility

• Certifications: ATEX II 2G Ex ib IIC T4, IECEx, UL 508, SIL 2 (IEC 61508), IEC 62443 (cybersecurity)
• Compatible Systems: Bently 3500/22M, 3500/40M, 3500/60M racks; Siemens PCS 7, Allen-Bradley ControlLogix, Honeywell Experion, Emerson DeltaV DCS
• Software Compatibility: Bently System 1®, Predix APM, Microsoft Azure IoT, AWS IoT

3. Advantages & Features

1. Multi-Protocol Flexibility: BENTLY 136188-02 supports Modbus TCP/IP, OPC UA, Ethernet/IP, and PROFINET, eliminating the need for external protocol converters and enabling direct integration with virtually all industrial control systems.
2. Redundant Communication Paths: Dual Ethernet ports and optional fiber connectivity provide seamless failover, ensuring BENTLY 136188-02 maintains data transmission even if one network link fails—critical for safety-critical applications like nuclear power plant machinery monitoring.
3. Low-Latency Data Transfer: With ≤30 ms latency, BENTLY 136188-02 delivers real-time machinery health data to control systems, enabling immediate response to anomalies such as excessive vibration or overspeed events.
4. Industrial-Grade Cybersecurity: Compliant with IEC 62443 standards, BENTLY 136188-02 includes firewalls, encryption, and access controls to protect against cyber threats, ensuring the integrity and confidentiality of machinery data.
5. Extreme Environmental Reliability: Rated for -40°C to +85°C operation and compliant with MIL-STD-810G for shock and vibration, BENTLY 136188-02 performs reliably in harsh environments like desert refineries, arctic power plants, and offshore platforms.

4. Application Fields & Cases

4.1 Application Fields

• Power Generation: Gas/steam turbine data integration with DCS, nuclear power plant machinery health monitoring, wind turbine gearbox data streaming to cloud
• Oil & Gas: Offshore platform compressor data transmission to ESD, pipeline pump condition monitoring via SCADA, LNG plant cryogenic equipment analytics
• Petrochemical: Refinery reactor agitator data integration with APM platforms, chemical plant extruder health monitoring, ammonia synthesis compressor alarm transmission
• Manufacturing: Steel mill rolling mill data sharing with plant-wide MES, paper mill dryer cylinder condition monitoring, cement plant kiln roller analytics

4.2 Typical Cases

1. Nuclear Power Plant Turbine Monitoring: A nuclear power plant deployed BENTLY 136188-02 to connect 3500 racks (monitoring turbine vibration and speed) with the Siemens PCS 7 DCS and safety system. The module’s redundant Ethernet ports ensured uninterrupted data flow during a network switch failure, preventing loss of critical safety-related data.
2. Offshore Oil Platform Compressor Control: An offshore platform used BENTLY 136188-02 to link compressor vibration and temperature data to the ESD system and cloud-based APM platform. The module’s OPC UA encryption protected sensitive data during transmission, while its low latency enabled the ESD to trigger a shutdown within 50 ms of detecting a critical fault.
3. Refinery APM Integration: A petrochemical refinery integrated BENTLY 136188-02 with its Honeywell Experion DCS and Predix APM platform. The module streamed real-time reactor compressor data, enabling predictive maintenance that reduced unplanned downtime by 35% and cut maintenance costs by $400,000 annually.

5. Competitor Comparison

6. Selection Suggestions & Precautions

6.1 Selection Suggestions

1. Protocol Requirements: BENTLY 136188-02 is ideal for multi-protocol integration (e.g., OPC UA + PROFINET); for basic Modbus-only needs, select Bently 136188-01 (cost-optimized version).
2. Redundancy Needs: Choose dual Ethernet + fiber options for safety-critical applications (e.g., nuclear power, offshore platforms); standard Ethernet-only configurations suffice for non-critical machinery monitoring.
3. Environmental Conditions: Select ATEX/IECEx-certified units for explosive zones (e.g., refineries, chemical plants); opt for IP65 enclosures for outdoor or dusty installations (e.g., mining facilities).

6.2 Precautions

1. Network Configuration: Configure dual Ethernet ports in failover mode (not load-balanced) via the 3500 rack controller; use shielded Ethernet cables and ground them at the module end to minimize EMI.
2. Cybersecurity Setup: Enable OPC UA encryption and ACLs to restrict access to BENTLY 136188-02; update firmware regularly (via System 1® software) to patch security vulnerabilities and enable new protocol features.
3. Maintenance Checks: Inspect network connections and fiber ports (if equipped) every 6 months for corrosion or damage; test failover functionality quarterly to verify redundant path reliability.
4. Installation Guidelines: Mount BENTLY 136188-02 in the 3500 chassis’s dedicated communication slot, with at least 5 cm clearance from power modules to avoid heat interference; avoid installation near high-voltage equipment or VFDs.
