ABB TU810V1 3BSE013230R1

Description

Product Description

The ABB TU810V1 3BSE013230R1 is a specialized communication and termination unit, often functioning as a local operator interface module, within ABB’s Advant Controller 400 Series (AC 400) platform. This unit serves as a critical local hub, providing connection points for operator panels, programming terminals, and other peripheral devices to the central controller. The ABB TU810V1 3BSE013230R1 is designed to facilitate on-site monitoring and intervention, featuring a robust housing with integrated terminals for various communication cables. It typically provides power and signal conditioning for connected operator units, ensuring reliable local interaction with the control process. For facilities operating with the AC 400 system, the availability and proper functioning of the ABB TU810V1 3BSE013230R1 are essential for local operability and maintenance tasks. This unit exemplifies ABB’s focus on providing comprehensive system components that enhance usability. Sourcing the genuine ABB TU810V1 3BSE013230R1 (Product Link) is crucial for maintaining the integrity and functionality of the local operator station in these industrial control systems.

Product Parameters

• Product Type: Termination Unit / Local Operator Interface Module

• Brand & Series: ABB, Advant Controller 400 Series (AC 400)

• Model: ABB TU810V1 3BSE013230R1

• Primary Function: Termination and interface unit for local operator panels (e.g., Advant Operator 100 series panels) and programming devices.

• Connectivity: Provides terminal connections for communication cables (e.g., for serial links to the controller) and power supply for the connected operator station.

• Compatibility: Designed specifically to interface with ABB AC 410/AC 450 controllers and corresponding operator station hardware.

• Mounting: Typically designed for standard DIN rail mounting within a control cabinet.

• Status Indication: May include LEDs for indicating power and communication status.

• Power Supply: Accepts a standard DC supply voltage (e.g., 24V DC) to power itself and the attached operator terminal.

• Environmental Rating: Designed for standard industrial panel-mounted environments.

Advantages and Features

The ABB TU810V1 3BSE013230R1 offers distinct advantages for system integration and maintenance. Its key feature is Simplified and Standardized Connectivity, providing a dedicated, robust interface point that eliminates guesswork in wiring local operator stations. The unit ensures Reliable Power Distribution to the connected panel, protecting sensitive electronics from voltage fluctuations. It enhances System Serviceability by centralizing the connections, making it easier for technicians to connect programming laptops or replace operator panels without disturbing the controller’s main wiring. The ABB TU810V1 3BSE013230R1 also contributes to Improved System Organization within the control cabinet, leading to cleaner wiring and easier troubleshooting. By using the designated ABB TU810V1 3BSE013230R1 (Product Link), engineers ensure compatibility and reliable communication between the operator interface and the core controller.

Application Cases in Various Fields

This termination unit is found in industries that deployed the ABB AC 400 series for process control and required local operator stations.

• Pulp and Paper Mills: Providing local control station interfaces for operators to monitor and adjust sections of the paper machine, like the wet end or dryer section.

• Chemical Processing Plants: Serving as the connection point for operator panels near batch reactors or distillation columns for local recipe management and manual overrides.

• Metals Production: Facilitating local operator interaction with control systems for rolling mills or furnace controls.

• Power Plant Auxiliary Systems: Used in local control rooms for subsystems like water treatment or ash handling within a larger power generation facility.

• Marine Automation: Integrating operator panels on the bridge or in engine control rooms for monitoring propulsion and auxiliary systems.

Comparison with Competing Products

Compared to generic terminal blocks or power supplies used to connect a display, the ABB TU810V1 3BSE013230R1 is a purpose-engineered system component. Its competitors would be similar termination/interface units from other major DCS vendors of the same era, such as Siemens (for their Simatic series) or Honeywell. The ABB TU810V1 3BSE013230R1 is distinguished by its optimized design for the specific electrical and communication requirements of ABB’s Operator 100 series panels and AC 400 controllers. It offers a plug-and-play level of integration that generic components cannot, ensuring correct signal levels, pinouts, and grounding. While functionally simple, its value lies in guaranteeing system reliability and reducing commissioning errors.

Selection Suggestions and Precautions

• Selection Suggestions:

  1. Verify Exact System Configuration: Confirm that this termination unit is the correct model for your specific AC 400 controller (AC 410/450) and the specific model of the attached operator panel (e.g., OPC100, OPU100).

  2. Check the required cable types and pinouts between the ABB TU810V1 3BSE013230R1, the controller, and the operator panel to ensure you have the correct mating cables.

  3. Ensure the power supply characteristics (voltage, current) match the requirements of both the termination unit and the operator panel it will power.

  4. For legacy systems, consult the original system documentation or an ABB specialist to confirm compatibility before procurement.

• Precautions:

  1. Power Down During Installation: Always isolate power to the controller and the operator station before connecting or disconnecting wires from the ABB TU810V1 3BSE013230R1 to prevent electrical damage.

  2. Observe Polarity: Pay strict attention to the polarity (+/-) of the DC power supply connections as indicated on the unit’s labeling.

  3. Use Correct Cables: Only use the specified ABB communication cables or cables manufactured to the exact specification. Incorrect cabling can cause communication failure or damage.

  4. Secure Connections: Ensure all terminal screws are properly tightened to prevent loose connections, which can lead to intermittent faults that are difficult to diagnose.

  5. Source Authentic Parts: Due to the critical role in local operability, always procure the genuine ABB TU810V1 3BSE013230R1 (Product Link) from a reputable supplier to avoid compatibility issues and ensure reliability.
