ABB E3ES

Description

Product Description

The ABB E3ES is a compact, high-performance solid-state time relay from ABB’s ES series, designed for precise timing control in industrial automation. This relay offers exceptional accuracy and reliability in a space-saving design, making it ideal for panel builders and control system integrators. The ABB E3ES series features a clear, high-visibility time indicator and is known for its robust construction and easy installation via snap-on mounting. For detailed specifications and purchasing information, please visit the official product page for the ABB E3ES. Its versatility in timing functions makes the ABB E3ES a cornerstone component for coordinating sequential operations.

Product Parameters

• Supply Voltage: Available in a range of standard AC and DC voltages (e.g., 24V DC, 24-240V AC/DC).

• Timing Range: Multiple adjustable ranges, typically from fractions of a second up to hours, selectable via a rotary knob.

• Output Configuration: 1 changeover contact (SPDT).

• Contact Rating: Typically 8A at 250V AC, suitable for controlling contactors, solenoid valves, and small motors.

• Mounting: Designed for easy snap-on mounting on 35mm DIN rail (EN 60715).

• Time Setting: Analogue adjustment via a potentiometer with a clear scale.

• Operating Temperature: Standard industrial range, e.g., -20°C to +55°C.

• Standards Compliance: Conforms to relevant IEC/EN standards for safety and EMC.

Advantages and Features

The ABB E3ES time relay provides several key benefits. Its primary advantage is the combination of compact size and high switching capacity, saving valuable panel space without compromising performance. The intuitive, analogue dial allows for quick and easy setting without the need for complex programming. It boasts high immunity to electrical interference, ensuring stable operation in harsh industrial environments. The robust design ensures a long mechanical and electrical life. Furthermore, the wide range of available supply voltages makes the ABB E3ES highly adaptable to different control circuit designs.

Application Cases in Various Fields

• Manufacturing Automation: Controlling dwell times in assembly machines, managing step sequences in packaging equipment, and automating pump cycling in coolant systems.

• Building Management: Managing staircase lighting, controlling ventilation fans with delayed shutoff, and sequencing HVAC components.

• Infrastructure: Automating the run-time for water pumps in treatment facilities and controlling timing for conveyor belts in material handling systems.

• Motor Control Centers (MCCs): Providing star-delta changeover timing for motor starters or implementing auto-reset delays for pump alternation systems.

Comparison with Competing Products

Compared to basic pneumatic or less robust electronic timers from other brands, the ABB E3ES stands out for its superior build quality, wider operating voltage range, and ABB’s global service and support network. Against more advanced, programmable multi-function timers, the ABB E3ES excels in applications where simplicity, cost-effectiveness, and quick manual adjustment are prioritized over digital programmability. Its analogue setting is often seen as an advantage for maintenance personnel who prefer a direct, knob-based interface over navigating digital menus.

Selection Suggestions and Precautions

1. Voltage Match: Carefully select the correct ABB E3ES variant to match your control circuit’s supply voltage (AC or DC).

2. Timing Range: Choose a model with a timing range that comfortably covers your required delay interval to ensure precision.

3. Load Rating: Verify that the relay’s contact rating (8A) is sufficient for the inrush and steady-state current of the load (e.g., contactor coil) it will be switching.

4. Function: Confirm that the simple on-delay (or other available) function meets your application needs.

5. Environment: While robust, ensure the ambient temperature and humidity are within specified limits. For extremely dusty or corrosive environments, consider additional protection.
