ABB CPU0002

Description

Product Description

The ABB CPU0002 is a core Processing Unit designed for ABB’s Freelance distributed control system (DCS), a platform well-regarded for mid-range process automation. This central module, the ABB CPU0002, functions as the primary logic solver and system manager for its control node, executing the user-defined control strategy, managing I/O communication, and handling network data exchange. It is responsible for orchestrating all automation functions within its domain, from simple PID loops to complex sequential control. The design of the ABB CPU0002 emphasizes robustness, deterministic performance, and seamless integration with the AC 700F controller hardware family. It serves as the brain of the control station, making the selection and configuration of the correct ABB CPU0002 critical for system performance and reliability.

Product Parameters

The technical specifications of the ABB CPU0002 processing unit define its computational capabilities:

• Processor & Performance: Features a dedicated microprocessor with defined processing power (MIPS), suitable for handling a specified number of function blocks and I/O points.

• Memory: Includes integrated user memory (for the control program) and data memory (for process values and variables). Capacity is typically defined in kilobytes.

• Communication Ports: Equipped with multiple interfaces, commonly including:

  • An RS-232/485 port for local engineering/service access.

  • An Ethernet port (likely 10/100 Mbps) for integration into the plant network (TCP/IP) and connection to the Freelance Operator Station.

  • A Profibus DP or other fieldbus interface for connecting to remote I/O stations (e.g., ABB’s S800 I/O).

• I/O Handling Capacity: Supports a defined maximum number of I/O channels and function blocks, which dictates the scale of applications it can manage.

• Real-Time Clock: Includes a battery-backed real-time clock for time-stamping events and historical data.

• Operating Temperature: Rated for industrial control cabinet environments, typically 0°C to 60°C.

• Certifications: Complies with relevant industrial standards for EMC and safety.

Advantages and Features

The ABB CPU0002 offers several key benefits within the Freelance ecosystem:

• Integrated Engineering Environment: The ABB CPU0002 is programmed and configured using ABB’s Freelance Engineering software, which provides a unified environment for hardware configuration, control logic (CFC/SFC), and operator faceplates.

• Deterministic Control Performance: Offers predictable and consistent scan cycle times, which is essential for stable process control and reliable interlocking logic.

• Robust Communications: Its multi-port architecture allows simultaneous engineering access, operator interface communication, and high-speed fieldbus I/O scanning, enabling a truly distributed architecture.

• Compact and Rugged Design: As a dedicated DCS controller, the CPU0002 is built for 24/7 operation in industrial conditions, offering high reliability in a compact form factor.

• Scalable Solution: Part of a scalable family, allowing for system expansion by adding more I/O or connecting multiple controllers on the same network.

Application Cases in Industry

The ABB CPU0002 is commonly applied in medium-scale process and hybrid automation:

• Water and Wastewater Treatment: Controls filtration processes, chemical dosing, pump stations, and sludge handling in municipal and industrial treatment plants.

• Food and Beverage: Manages batch processes for mixing, cooking, and filling, as well as CIP (Clean-in-Place) sequences.

• Building Automation & HVAC: Serves as a central controller for large building management systems, coordinating chillers, air handlers, and lighting.

• Pharmaceuticals: Controls utilities systems (purified water, clean steam) and secondary packaging lines where GAMP guidelines are followed.

• Renewable Energy (Biogas/Biomass): Automates the process control for anaerobic digesters, biomass boiler systems, and gas upgrading units.

Comparisons with Competing Products

When compared to a standard PLC or other mid-range DCS controllers, the ABB CPU0002 presents a balanced proposition:

• DCS Functionality at a Competitive Price: The ABB CPU0002 delivers true DCS features—like integrated global database, advanced alarm management, and historian—often at a lower entry cost than larger, more complex DCS platforms, while offering more than a basic PLC.

• Simplified Architecture vs. High-End DCS: It provides an all-in-one controller with built-in networking, reducing the hardware complexity and engineering overhead compared to larger DCS systems that separate controller, network, and I/O processors.

• Superior Process Focus vs. Generic PLCs: While a PLC can perform the tasks, the CPU0002 and its Freelance software are optimized for process control with native support for complex analog loops, batch management, and seamless HMI integration out-of-the-box.

• Strong ABB Ecosystem Integration: Benefits from easy integration with other ABB drives and field instruments, and can act as a node within larger ABB system architectures.

Selection Suggestions and Precautions

Careful planning is required for successful implementation:

1. Assess I/O and Performance Requirements: Before selecting the ABB CPU0002, evaluate the total number of I/O points, the complexity of the control strategy (number of function blocks), and required scan times to ensure the CPU’s capacity is not exceeded.

2. Plan the Network Architecture: Define the network topology early. Decide how the Ethernet port will be used (for operators only, or also for peer-to-peer communication) and ensure the chosen fieldbus (e.g., Profibus DP) is suitable for the I/O location and response needs.

3. Secure the Engineering Software: Acquire the correct version of ABB Freelance Engineering software. The CPU0002 cannot be configured or programmed without it.

4. Handle Battery Replacement Proactively: The real-time clock battery has a finite life. Monitor its status and plan for replacement during scheduled maintenance to prevent loss of time-stamped data.

5. Source Authentic Firmware: Always load firmware obtained from official ABB sources. Unauthorized firmware can cause instability, communication failures, and void warranties.
