ABB 3BHL000986P0006

Description

Product Description

Technical Parameters

• Device Type: Power module for ABB medium-voltage drive systems (ACS series)
• Rated Voltage: 3.3 kV AC
• Rated Current: 400 A
• Operating Temperature Range: -25°C to +70°C
• Cooling Method: Forced air cooling / liquid cooling compatible
• Insulation Class: Class F (IEC 60085)
• Protection Rating: IP20 (for cabinet-mounted installation)
• Compatibility: ABB ACS 1000/2000 medium-voltage drives, ABB drive control units, ABB DriveMonitor software
• Certifications: CE, UL, CSA, IEC 61800-3, RoHS compliant

Advantages and Features

1. High Power Density and Efficiency

   ABB 3BHL000986P0006 boasts an optimized circuit design that maximizes power output while minimizing energy loss, achieving a conversion efficiency of over 98%. This high efficiency reduces operational costs and heat generation, extending the service life of both the module and the connected drive system.

2. Robust Thermal and Voltage Tolerance

   Equipped with advanced thermal dissipation components and overvoltage protection mechanisms, ABB 3BHL000986P0006 can withstand voltage surges up to 150% of the rated value and continuous operation at high temperatures, making it ideal for demanding industrial environments.

3. Seamless Integration with ABB Ecosystem

   Designed as an original equipment manufacturer (OEM) part for ABB drives, ABB 3BHL000986P0006 integrates flawlessly with ABB’s control systems and monitoring software. It supports real-time data transmission for performance tracking, fault diagnosis, and predictive maintenance.

4. Enhanced Reliability and Longevity

   Built with high-quality semiconductor materials and reinforced encapsulation, ABB 3BHL000986P0006 has a service life of over 15 years under nominal operating conditions, with a mean time between failures (MTBF) exceeding 100,000 hours.

5. Safety and Compliance

   The module meets strict international safety standards, with built-in overcurrent, overheating, and short-circuit protection functions to prevent equipment damage and ensure operator safety during maintenance and operation.

Application Cases

• Metallurgical Industry: ABB 3BHL000986P0006 is used in ABB medium-voltage drives to control rolling mill motors, providing precise speed regulation for steel production lines and ensuring consistent product quality.
• Water and Wastewater Treatment: Integrated into pump drive systems, the module enables energy-efficient operation of large water pumps, reducing power consumption by up to 30% compared to traditional fixed-speed drives.
• Mining Operations: Applied in conveyor belt drive systems, ABB 3BHL000986P0006 delivers stable power to motors in dusty, high-vibration mining environments, minimizing downtime and maintenance costs.
• Power Generation: Used in boiler feed pump drives for thermal power plants, the module ensures reliable motor control to maintain optimal boiler pressure and power generation efficiency.

Comparison with Competitors

• OEM Compatibility Advantage: Unlike generic power modules that require extensive configuration and may cause compatibility issues, ABB 3BHL000986P0006 is specifically engineered for ABB medium-voltage drives, eliminating protocol conflicts and ensuring plug-and-play functionality.
• Higher Efficiency and Durability: Compared to competing modules with typical efficiency levels of 95–96%, ABB 3BHL000986P0006 offers over 98% efficiency, resulting in significant long-term energy savings. Its robust construction also provides better resistance to harsh industrial conditions.
• Integrated Diagnostics: The module supports real-time fault monitoring and reporting via ABB DriveMonitor software, allowing for proactive maintenance, whereas many competitor modules lack built-in diagnostic capabilities and require external sensors.

Selection Recommendations and Precautions

Selection Recommendations

• Choose ABB 3BHL000986P0006 for upgrading or replacing power modules in ABB ACS 1000/2000 medium-voltage drive systems, especially in applications requiring high reliability and energy efficiency.
• This module is ideal for industries such as metallurgy, mining, and power generation, where equipment operates continuously under harsh conditions.
• Prioritize this module for projects focused on reducing energy consumption and maintenance costs through predictive monitoring.

Precautions

• ABB 3BHL000986P0006 is designed exclusively for ABB medium-voltage drive systems; do not use it with non-ABB drives without ABB’s official compatibility verification.
• Ensure the module is installed by qualified technicians following ABB’s installation guidelines to avoid improper wiring, which may lead to overheating or short circuits in ABB 3BHL000986P0006.
• Use only licensed ABB DriveMonitor software for configuration and diagnostics; unauthorized software may corrupt the module’s firmware and cause system malfunctions.
