5X00121G01

Description

Parameter Specifications

1. Power Supply
   The 5X00121G01 typically operates on a 24V DC power supply. The power consumption is relatively low, around 7 – 10W, ensuring energy – efficient operation in industrial settings.
2. Input/Output Channels
   • Digital Inputs: It is equipped with 4 digital input channels. These inputs are designed to interface with common digital sensors such as proximity sensors, limit switches, and photoelectric sensors. The input voltage range is 18 – 30V DC.
   • Digital Outputs: There are 2 digital output channels. Each output channel can handle a resistive load of up to 1.5A and an inductive load of up to 0.8A, suitable for controlling relays, solenoid valves, and small – sized motors.
3. Communication Interface
   The 5X00121G01 supports the Modbus RTU communication protocol over an RS – 485 interface. The communication speed can reach up to 9600 bps, allowing for efficient data exchange with other devices in an industrial network, such as Programmable Logic Controllers (PLCs), Human – Machine Interfaces (HMIs), and Supervisory Control and Data Acquisition (SCADA) systems.

Uses

1. Small – Scale Industrial Automation
   In small – scale manufacturing workshops, the 5X00121G01 can be used to monitor and control simple production processes. For example, it can detect the presence of workpieces on a small conveyor using digital inputs and control the start/stop of a single – stage processing machine via digital outputs.
2. Building Automation in Small Areas
   In small commercial buildings or specific areas within larger buildings, it can manage basic building functions. It can be connected to door sensors and occupancy sensors to control the lighting in a small room or the operation of a single ventilation fan.
3. Agricultural Automation (Micro – Scale)
   In micro – scale agricultural facilities, such as small home gardens or greenhouses, it can monitor environmental parameters like the opening and closing status of small vents through connected sensors and control small – scale irrigation valves accordingly.

Weight and Dimensions

1. Weight
   The 5X00121G01 weighs approximately 0.5 – 0.8 kg, which is relatively light, facilitating easy installation and handling.
2. Dimensions
   It has a compact design with dimensions around 100mm (length) x 80mm (width) x 30mm (height). This small size allows it to be installed in standard control cabinets or on DIN rails without taking up much space.

Characteristics

1. Cost – Effective Solution
   The 5X00121G01 offers an affordable option for small – scale automation projects. It provides essential input/output and communication capabilities at a reasonable price.
2. Easy Configuration
   The device can be easily configured using simple software tools. Users can set up input/output parameters, communication settings, and diagnostic functions without complex programming knowledge.
3. Electrical Isolation
   It features electrical isolation between input/output channels and the power supply. This helps prevent electrical interference and protects the device and connected equipment from damage.

Stability and Reliability

1. Robust Construction
   The 5X00121G01 has a durable housing that can withstand normal industrial vibrations, dust, and moderate temperature variations.
2. Fault Protection
   It is equipped with over – current and over – voltage protection circuits. These safeguard the device from electrical faults, ensuring reliable operation over time.
3. Long – Term Testing
   The device has undergone long – term testing under various operating conditions to verify its stability and reliability, giving users confidence in its performance.
